Analog Speed Dome User Manual UD.
1 User Manual of Analog Speed Dome Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact the dealer. This manual is applicable to Analog Speed Domes. This manual may contain several technically inaccurate points or printing errors, and the content is subject to change without notice. The updates will be added into the new version of this manual. We will readily improve or update the products or procedures described in the manual.
2 User Manual of Analog Speed Dome Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
3 User Manual of Analog Speed Dome Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
4 User Manual of Analog Speed Dome Cautions: Make sure the power supply voltage is correct before using the product. Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places. Do not expose it to high electromagnetic radiating environment. Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal damage to the product.
5 User Manual of Analog Speed Dome Table of Contents Chapter 1 Overview .............................................................................................................................................. 7 1.1 Description ........................................................................................................................................................... 7 1.2 Functions .....................................................................................................
6 User Manual of Analog Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance .............................................................................................. 46 Appendix 4 Table of Wire Gauge Standards ...................................................................................................................
7 User Manual of Analog Speed Dome Chapter 1 Overview 1.1 Description Integrated with the built-in pan/tilt unit, the speed dome features highly sensitive response and reliable performance. The speed dome can be adopted in various surveillance fields with its full-integral functions and features, such as corridor, large venue, meeting room, station, community, etc. 1.2 Functions Note: The functions vary according to the different models of the speed dome.
8 User Manual of Analog Speed Dome Label Display The on-screen label of the preset title, time, zoom and other operations can be programmed by menu and displayed on the monitor. Auto Flip In manual tracking mode, when a target object goes directly beneath the dome, the dome will automatically rotate 180 degrees in horizontal direction to maintain continuity of tracking. Privacy Mask The privacy mask allows a user to program user-defined areas that cannot be viewed by the operator of the dome system.
9 User Manual of Analog Speed Dome random scan, frame scan, panorama scan, day/night mode or none.
10 User Manual of Analog Speed Dome Chapter 2 Getting Started 2.1 Power-up Action After the power is connected, the speed dome will perform a series of self-test actions. It performs lens actions firstly, then the panning movement and the tilting movement at last. After the power-up self-test actions, the system information will be displayed for 2 minutes on the live view screen as shown below. TYPE SN XX-XXXX-X XXXXXXX ADDRESS COM FORMAT 0 2400,8,1 PROTOCOL VERSION ADAPTIVE 0.
11 User Manual of Analog Speed Dome 2.2 Basic Operations You can operate the speed dome using a control device. The control devices include the control keyboards, DVRs, DVSs, etc. In this and the following chapters, operation of the speed dome by the IE browser of a DVR will be taken as an example. Panning and tilting: Click the direction buttons to control the pan and tilt movement of the speed dome. Zooming: Click the ZOOM+ and ZOOM- buttons to control the zooming.
12 User Manual of Analog Speed Dome Note: For Manchester code control protocol, the system-defined presets with special functions are shown as below: Table 1-1 System-defined Presets of Manchester Code Control Protocol Set Preset No. 65 66 69 70 71 72 Function Remote reboot Access main menu Stop recording pattern Record Pattern 1 Record Pattern 2 Record Pattern 3 Call Preset No. 67 70 71 72 Function Auto-flip Run Pattern 1 Run Pattern 2 Run Pattern 3 2.
13 User Manual of Analog Speed Dome Chapter 3 Menu Operation The OSD menu tree is shown in the following figure. Note: The menu varies depending on the model of speed dome.
14 User Manual of Analog Speed Dome 4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ control panel of the DVR.
15 User Manual of Analog Speed Dome similar to the system information shown after the power-up action. Please refer to Section 2.1 for more details. Enter the system information display menu: MAIN MENUS > SYS INFO SYS INFO TYPE XX- XXXXX-X ADDRESS 0 COM FORMAT 0000,0,0 PROTOCOL XXXXX VERSION 0. 00 HARDVERSION BUILD DATE 0. 00 13 08 05 BACK EXIT Figure 3-3 System Information Notes: Information on this menu cannot be edited.
16 User Manual of Analog Speed Dome If the SOFT ADDR is set to OFF, the hard address set by the DIP switch is the valid address of the speed dome. Task 2: Set the broadcast address of the speed dome. When the BROADCAST ADDRESS is set to ON, the control devices with address 0 can control the speed dome remotely regardless of the address of the speed dome. With this function on, the control device with address 0 is capable of controlling all domes connected to it. This function is usually for debugging.
17 User Manual of Analog Speed Dome 2. Click the left/right/up/down direction buttons to adjust the view angle. 3. Click IRIS+ button to confirm and exit. IR LED Parameters IR PARAMETER IR SENSITIVITY LOW N/M LED CURRNT FAR LED CURRNT 2 2 REFERENCE HEIGHT(M) N/A REFERENCE ZOOM LED CONTROL BACK N/A AUTO EXIT Figure 3-6 IR Parameter IR Sensitivity: When the LED CONTROL mode is AUTO, the IR LEDs are turned on or off according to the illumination of the scene.
18 User Manual of Analog Speed Dome RS-485 checksum setting You can set the 485CHECK SET as ON or AUTO for improving the controlling effect. Coaxitron Settings The Coaxitron transmission function can be enabled to transmit the RS485 signal along with the video signal via the BNC cable. If the connected encoding device supports the Coaxitron transmission as well, the RS485 cable will not be necessary.
19 User Manual of Analog Speed Dome Task 1: Configure the focus settings. Setting the focus mode Steps: (1) Move the cursor to FOCUS using the direction buttons and click IRIS+ to enter. (2) Click up/down direction buttons to set the focus mode to AF, MF or HAF. AF (Auto-focus): The lens remains in focus during PTZ movements. MF (Manual Focus): You need to adjust the focus with Focus+ and Focus- buttons manually.
20 User Manual of Analog Speed Dome (1) IR cut filter. It can be set as AUTO, DAY or NIGHT. AUTO: The speed dome is capable of automatically switching from Black and White mode (NIGHT) and Color mode (DAY) regarding to the lightening conditions. It is the default mode. NIGHT (B/W): You can switch the IR cut filter into Black and White mode to increase then lens sensitivity in low light conditions DAY (Color): You can switch it to DAY mode in normal lighting conditions.
21 User Manual of Analog Speed Dome Set the Gain Gain value. The value of gain indicates the amplification degree of the original image signal. You can set the value from 0 to 15. Gain limit. The higher gain value you set, the more noises will appear in the image. You can set the maximum user configurable gain value from 0 to 15 to limit the gain range and control the noises in the image. Gain limit function varies according to the different camera models.
22 User Manual of Analog Speed Dome HAUTO: Selecting this mode, the viewed image retains color balance automatically according to the current color temperature. Task 9: Configure the image flip. If you turn the IMAGE FLIP function on, the image will be flipped 180 degree along its central axis, like the mirror reflection of the image. Task 10: Configure the INIT LENS. You can turn INIT LENS on to trigger a spontaneous lens initiation to ensure the normal operation. Task 11: Configure the noise reduction.
23 User Manual of Analog Speed Dome 1. Move the cursor to enter the privacy mask configuration submenu: MAIN MENUS > DOME SETTINGS > PRIVACYS PRIVACY BLANKS BLANK NUM 1 BLANK STATUS SET BLANK OFF CLEAR BLANK BACK EXIT Figure 3-8 Privacy Mask Configuration Menu 2. Choose the privacy mask number: Steps: (1) Move the cursor to BLANK NUM and click IRIS+ to enter the editing mode. (2) Click the up and down direction buttons to select a mask number for configuration.
24 User Manual of Analog Speed Dome 4. Enable or disable the privacy mask function. Move the cursor to BLANK STATUS. Click IRIS+ button to enter the editing mode and click the up and down direction buttons to set it ON or OFF. Note: If no privacy mask has been configured, you cannot set the status as ON. 5. Delete the privacy mask. You can enter the CLEAR BLANK menu to delete the current privacy mask. 3.3.
25 User Manual of Analog Speed Dome Figure 3-11 Get the Codes of a Character (2) On the SET TITLE menu, call the presets standing for each code in sequence to enter the codes. E.g. call preset 10 to get 0, and call preset 2 to get 2. The corresponding numbers, characters and position information will be displayed on the screen when you are calling the presets. (3) You can call preset 16 to delete the character at the current position. Note: You can set up to 15 characters for the dome title. 9.
26 User Manual of Analog Speed Dome choose each display mode as ON or OFF, and define each display time as 2 seconds, 5 seconds or 10 seconds. 4. Click IRIS+ button to confirm. Note: If you enable the ZOOM and PT OSD both, while calling a preset, the preset label will be displayed on the screen until the preset finishes. The speed dome shows the viewing direction when you manually control it to rotate.
27 User Manual of Analog Speed Dome automatically reduce or increase the panning and tilting speed according to the zooming amount. This function enables the speed dome to trace the object at a proper speed when the speed dome is zooming and the monitored scene is narrowed (zoom in) or enlarged (zoom out). You can set PROPORTIONAL PAN as ON or OFF to enable/disable the function. Note: This function is enabled automatically while setting the patterns.
28 User Manual of Analog Speed Dome the new settings. 4. Follow the prompts to configure the right, up and down limit stops on the menu. Note: The new limit stops will overwrite the existed ones by default. 5. You can clear the defined limit stops. Click IRIS+ to enter CLEAR STOPS and click IRIS+ again to clear the stops. Elevation set You can set ELEVATION SET as ON to increase the elevation angle range of the speed dome or set it as OFF to disable the function.
29 User Manual of Analog Speed Dome Note: The preset position settings will be restricted by the limit stops if they are defined. 4. Call the presets. You can select the preset number from the drop-down preset list in the control panel of the encoder through a web browser, and click the arrow to call a user-defined or system-defined preset. 5. Clear the preset settings. Move the cursor to CLEAR PRESET and click IRIS+ to clear the settings of the current preset. 3.4.
30 User Manual of Analog Speed Dome NUM PRESET DWELL SPEED 1 0 6 30 2 0 6 30 3 0 6 30 4 0 6 30 5 0 6 30 6 7 0 0 6 6 30 30 DONE: OPEN QUIT:CLOSE Figure 3-16 Edit the Patrol (2) Click up/down direction buttons to choose the number and locate the preset to be edited. (3) Click left/right direction buttons to position the cursor to the column of PRESET, DWELL and SPEED. You can click the up/down direction buttons to set the value of preset number, dwell time and patrol speed.
31 User Manual of Analog Speed Dome Steps: 1. Move the cursor to enter the PATTERNS submenu: MAIN MENU > DOME SETTINGS > PATTERNS PATTERNS PATTERN NUM EDIT PATTERN 1 PREVIEW CLEAR PATTERN REMAINING BACK 100 EXIT Figure 3-17 Pattern Configuration Menu 2. Choose the pattern number. Steps: (1) Move the cursor to PATTERN NUM and click IRIS+ to enter edit mode. (2) Click the up/down direction buttons to select the number of the pattern which is to be configured.
32 User Manual of Analog Speed Dome remaining memory shown under PATTERNS menu as REMAINING. The pan/tilt movements and the lens operations cannot be memorized simultaneously. 4. Preview the pattern. Enter the PREVIEW menu to preview the current pattern. 5. Call the defined pattern. You can call the special presets to call the defined pattern. E.g. call preset 41 to call pattern 1. Please refer to Section 2.3 to find the corresponding preset number for each pattern. 6. Delete the patterns.
33 User Manual of Analog Speed Dome Steps: (1) Move the cursor to TASK STATE and click IRIS+ to enter edit mode. (2) Click the up/down direction buttons to set the task status to ON. (3) Click IRIS+ again to confirm the settings and exit edit mode of this column. Note: If the task action and task time have not been configured, you cannot set the status as ON. 4. Configure the task action. Steps: (1) Move the cursor to TASK ACTION and click the IRIS+ to enter edit mode.
34 User Manual of Analog Speed Dome A zone is a panning and tilting area defined by the left/right and up/down limit stops. You can configure the zones on ZONES submenu. You can define a zone when the targeted surveillance scene is limited. Steps: 1. Move the cursor to enter the zone configuration submenu: MAIN MENU > DOME SETTINGS > ZONES ZONES ZONE NUM 1 [UNDEFINED ] EDIT ZONE ZONE STATUS SCAN STATUS ON ON CLEAR ZONE BACK EXIT Figure 3-21 Zone Configuration 2.
35 User Manual of Analog Speed Dome You can clear all user-defined PTZ control settings, including presets, patrols, patterns, zones and time tasks. You can also clear privacy masks on this menu. Steps: 1. Enter the CLEAR SETTINGS menu: MAIN MENU > DOME SETTINGS > CLEAR SETTINGS CLEAR SETTINGS CLEAR ALL PRESETS CLEAR ALL PATROLS CLEAR ALL PATTERNS CLEAR ALL BLANKS CLEAR ALL ZONES CLEAR ALL TIME TASKS BACK EXIT Figure 3-22 Clear Dome Settings 2. Move the cursor to each item, e.g.
36 User Manual of Analog Speed Dome Item Description POWER UP The occurrence times of abnormal reboot PAN LOST The occurrence times of panning loss TILT LOST The occurrence times of tilting loss CAMERA LOST The occurrence times of communication loss Note: The panning loss and tilting loss refer to the failures of panning and tilting movement, and are for diagnosing the electric motor of the speed dome. 3.
37 User Manual of Analog Speed Dome 3.6.1 Configuring Alarm Input and Linked Actions Purpose: This section explains how to configure the speed dome to respond to alarm events with alarm linked actions, such as calling presets, patrols, patterns, scanning, etc. Steps: 1.
38 User Manual of Analog Speed Dome If multiple alarms with different priorities are triggered at the same time, the dome only responds to the alarm with the highest priority. If multiple alarms with the same priority are triggered at the same time, then the dome will respond to each alarm according to the defined alarm sequence. 3.6.
39 User Manual of Analog Speed Dome AUX AUX1 DWELL TIME AUX2 CLOSE 2 OPEN DWELL TIME BACK 0 EXIT Figure 3-26 Configure the AUX Output 2. Click IRIS+ to edit the status of the auxiliary outputs. You can set the alarm output type as OPEN (normally open) and CLOSE (normally closed). Note: there are 2 auxiliary outputs configurable. 3. Move the cursor to DWELL TIME to set the duration of the auxiliary output signal. The configurable rage is 0~60 seconds. 4.
40 User Manual of Analog Speed Dome 2. Click IRIS+ to enter edit mode. 3. Click the left/right buttons to select the digit of the current password and click up/down or FOCUS+/- buttons to set the new value. 4. Click the right direction button to move the cursor to INPUT PW AGAIN and input the password again. 5. Click IRIS+ to save the new settings and exit. 6. Enter the START USING submenu and switch the status to ON and click IRIS+ to save.
41 User Manual of Analog Speed Dome AE mode Exposure compensation White balance Auto-flip Proportional pan Park time Park act Scan speed Image freeze Limit stops Time show Zone show Address show Error rate show Zoom/PT/Preset show Auto 7 Auto On On 5 seconds None 28 Off Off Off On Off Off Off 3.7.4 Restoring Default Camera Settings Enter MAIN MENU > RESTORE CAMERA Click IRIS+ to restore the camera settings to the default value; or click IRIS- to exit.
42 User Manual of Analog Speed Dome Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by pulse signal that is below 3000V, like instantaneous lighting stroke, surging, etc. According to the actual outdoor situation, necessary protection measures must be taken, besides ensuring the electrical safety. The distance between signal transmission wires and High-voltage equipment or high-voltage cable is at least 50m.
43 User Manual of Analog Speed Dome Appendix 2 RS485 Bus Connection General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impendence, the maximum load ability is 32 payloads (including controller device and controlled device). RS485 Bus Transmission Distance When using 0.56mm (24AWG) twisted-pair line, according to different baudrate, the maximum transmission distance theory table is shown as below: Table A-1 Max.
44 User Manual of Analog Speed Dome faraway. At this time, the dome will be uncontrollable, or self-running, etc. 1# 6# 控 主 备 设 Controller Device 32# 15# Figure A-4 Star Shape Connection For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability. Show as figure 5.
45 User Manual of Analog Speed Dome Problem dome can be controlled but not smoothly. © Hikvision Possible Reasons To Solve the Problem tightly. 2. RS485+ or RS485-wire is 2. Change a RS485 wire. broken. 3. The speed dome is too far away 3. Add a terminal resistor. from the remote control device. 4. Too many speed domes are 4. Add a RS485 distributor. connected.
46 User Manual of Analog Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum voltage loss rate is 10% allowable. For example, for a device with the rating power of 80VA which is installed at a distance of 35 feet (10m) away from the transformer, then 0.8000mm is required as the minimum wire gauge. 0.8000 1.
47 User Manual of Analog Speed Dome Appendix 4 Table of Wire Gauge Standards Bare Wire Gauge(mm) 0.750 0.800 0.900 1.000 1.250 1.500 2.000 2.500 3.000 © Hikvision American Wire Gauge AWG 21 20 19 18 16 15 12 British Wire Gauge SWG 21 20 19 18 17 14 Cross-sectional Area of Bare Wire(mm2) 0.4417 0.5027 0.6362 0.7854 1.2266 1.7663 3.1420 4.9080 7.
