User's Manual

1.1.3 Product Guide
The iCLASS SE reader module comes in two form factors. It can also be configured for high
frequency card reading only or High & low frequency (prox).
In addition there are two different levels of security provided.
Key Security Notes:
Standard V1 Security: Standard Security (Version 1) Keyset – coupled with the Standard
13.56 MHz interpreter provides compatibility with iCLASS SE, iCLASS SR, standard iCLASS,
SE for MIFARE Classic and SE for MIFARE DESFire EV1 credentials.
Standard V2 Security: Standard Security (Version 2) Keyset – coupled with the SIO (Only)
13.56 MHz interpreter provides compatibility with iCLASS SE, MIFARE Classic SE and
MIFARE DESFire EV1 SE credentials
Elite Security: Elite reads only SE Elite™ credentials with unique matching keys. Works with
iCLASS SE, iCLASS SR, standard iCLASS, SE for MIFARE Classic and SE for MIFARE
DESFire EV1 with matching Elite keys. Requires ICE reference number.
Prox Reading Notes:
Standard Prox: HID Prox, AWID, EM4102 and Indala (10022 – 26-bit)
Custom Prox: HID Prox, AWID, EM4102 and Indala Custom format
For full ordering information including options, see the Embedded Technology Solutions How
to Order Guide:
http://www.hidglobal.com/documents/embedded_htog_en.pdf
.
1.2 Scope/Purpose
This document describes the hardware features of the iCLASS SE Reader Module. The
product is available in two form factors with various different configurations. Form factor and
host connectors are backward compatible to the OEM75 module.
1.3 Terms and Abbreviations
Abbreviation
Description
ANT
Antenna
ARM
Advanced RISK Machine
CSN
Card Serial Number
DNC
Do Not Connect
EMC
Electro Magnetic Compatibility
FSK
Frequency Shift Keying
FCC
Federal Communication Commission
HF
High Frequency (13.56 MHz)
LED
Light Emitting Diode
NPM
Normal Power Mode
PICC
Proximity IC Card
