HID Connect Applications Engineering staff will provide RF integration review and conceptual
training for integrators. In addition, HID provides antenna optimization and design services
through a Customer Product Opportunity Program.
7.3 4090A10 HF Antenna
Figure 15: 4090A10 HF Antenna
The 4090A10 HF antenna has an impedance of 50Ω and is optimized for operation with a
50mm ribbon cable. The antenna is tuned for a free air environment.
7.3.1 Mechanical Data
Detailed drawings are available at the iCLASS SE Reader micro-site.
