command indicators and the Seal Long Status indicators (Items #5 and #6
in Figure 7-0).
7.4.4 Cyclical Interrogations Options
The Cyclical Interrogations control frame (Figure 7 -0 ) cont ains some
options that allow you a variety of ways to execute cyclical interrogations.
In the No. of cycles box you can
enter the number of cycles that will
be executed. If you enter "-1", the
Evaluation Software will execute
interrogations until you click on the
Stop Cycle butt on. Even if No. of
cycles is not "-1", you can click on
the Stop Cycle button to stop the
interrogations.
In the System Pause field you can specify the pause between one
interrogation to the next in seconds.
The Loop through all Readers check box is available if more than 1
DataReader is defined. If this check box is checked, the Evaluation
Software will execute the first interrogation using the first DataReader in
the list, the second interrogation using the second DataReader and so on.
After the last DataReader was used, the first one is used again, and so on.
For example, it there are 3 DataReaders, and No . o f cy cles is 8, t he order
that the DataReaders will interrogate will be: 1,2,3,1,2,3,1,2.
The Session # box indicates the sequential number of the interrogation. T he
Evaluation Software increases this value with each new interrogation. T o
reset this number, and to clear the Broadcast Verify responses list, click the
Reset but ton.
Figure 7-0
