Chapter 7 Evaluation Software

Hi-G-Tek Ltd. Micro electronics & Asset Tracking Technology - 97 -

Seal ID into the Seal ID box (Item

#3b in Figure 7-0). Another option

is to select the Seal ID from the

Broadcast Verify responses list

(It em #7 in Figure 7-0), if it

previously responses to Broa dcast

Verify.

As in the B roadcas t Ve ri fy frame,

here you also have the Single

Interrogation and t h e Cycli cal Inte rrogati on options: clicking the Single

Interrogation button will execute the Addre sse d Ve rify command only

once, while clicking the Cyclical Interrogation button will execute the

Addressed Verify command cyclically according to the options that are

selected in the Cyclical Interrogations control frame (Item #8 in Figure 7-0)

as described in section 7.4.4.

The result (response) of the Addresse d Ve rify is displayed in the

Addressed Veri fy response indicat ors (It em #5 in Figure 7-0) and in t he

Seal St at us indicat ors (It em #6 in Figure 7-0).

The Addressed Ve ri fy response indicators contains the following fields:

 Data & Time – The current date and time in UTC (GMT) as returned

by the DataSeal.

Figure 7-0
