mark it and click on the Remo ve button.
The Evaluation Software assigns a Reader Address to each configured
DataReader automatically.
7.2.2 Setting Up the Comm unication Port
In the Readers Administration window, click on the Comm. Port drop
down list to define the
communication port that the
DataReaders are connected to.
Click on the Baud Rate drop
down list t o t he right of the
Comm. Port drop down list to
define t he baud rat e of t hat port .
Once you have made your
selection, click on the Set Comm
Port button. Figure 7-0 shows the
Readers Administration
window.
7.3 Reader Setup
The Reade r Setup window allows you to view and to modify the
parameters of the DataReaders. A complete description of each parameter
is given in chapter 8.
To open the Reader Setup window,
click on the Reade r Setu p icon in the
toolbar or select the Re a de rs men u and
then the Re ader Se tup item as shown in
Figure 7-0.
Figure 7-0
Figure 7-0
