5. OrgID matches, De pa rtmen t matches, and ADI matches: DataSeal
will respond without limitations.
6. OrgID matches, and ADI doesn't match: DataSeal will not respond.
Table 6-2 : OrgID, Department, and ADI
OrgID Department ADI Effe ct:
Match Match Match DataSeal will Respond
without any limitations.
Match Match/
Unmatched
Unmatched DataSeal will not
respond
Match Unmatched Matched/
Unmatched
DataSeal will not
respond
Unmatched Match/
Unmatched
Match/
Unmatched
DataSeal will not
respond
6.6 DataSeal's Memory
The Dat aSeal's Memory is divided int o 2 sect ions: Event s Memory and
User Data.
6.6.1 Events Memory
This memory stores the Events detected by the DataSeal during normal
operation. This memory can contain up to 55 Event records.
The memory has a FIFO type structure with 2 segments: T he first segment
can store 45 Events and is a simple FIFO buffer. The second segment can
store 10 Events and is a cyclic buffer with the last Events detected.
