4. Suspende d Se t – A Suspende d Set command was performed, and the
Sealing Wire wasn't closed yet.
5. Se aling Wi re Ch ange d – Indicates that the Sealing Wire's electronic
characteristics have changed since the DataSeal was Set.
6. Deep Sleep – Indicates that the DataSeal is in Deep Sleep mode.
7. General Error – Indicates an error with the DataSeal that is not
represented in the DataSeal's Short Status.
8. Approved O pen – If the DataSeal Opened flag is on, the Approve d
Open flag means that the opening is approved. If the DataSeal's
Opened flag is off, it means that the next open will be approved, if
performed during a certain period.
The DataSeal's Long Status contains the Short Status flags as well as 3
additional bytes that together represents the complete DataSeal's status. For
a det ailed descript ion of the Long Status, see chapter 8.
6.4 System Planning
When planning an application, attention should be paid to both system
operat ion and topology. Applicat ion requirement s and elect romagnet ic
environment characteristics should also be taken into account.
2 basic types of applications are possible: Fixed DataReader applications
and Mobile DataReader applications. A complex application that combines
DataReaders in both configurations is also possible.
The Fixed DataReader applications are applications where the DataReaders
are mounted at a fixed site. The Mobile applications are situations where
the DataReaders are mounted on vehicles for monitoring DataSeals in
transit. Mobile applications are normally implemented using the
TrackingDataReader, but may also be implemented using a DataReader
