User Manual

Chapter 5 DataReader Installation and Operating Instructions
- 42 - Hi-G-Tek Ltd. Micro electro nic s & A sset Tra cking Techno logy
5
DataReader Installation
5.1 Outdoor DataReader Installation
 The DataReader should be mounted on a smooth, flat surface.
 To mount the unit, insert 4 screws into the holes on the unit and fix to
the surface.
 A 6mm plastic anchor and 35mm pan head tapping screw is
recommended.
5.1.1 Ceiling Installation
The DataReader can be mounted on the ceiling. In such cases it is requested
to mount the antenna perpendicular to the ceiling using a 90° connector.
The figure below shows the DataReader installed on a ceiling, with the
