Chapter 4 DataTag Installation
- 38 - Hi-G-Tek Ltd. Micro electro nic s & A sset Tra cking Techno logy
4
DataTag Installation
The Dat aTag is delivered wit h a set of double-sided
tapes that are used for placing the DataTag on the
t agged object .
The Sensor Plate (item #1) is supplied separately
from the DataT ag. To place the Sensor Plate peel
t he paper from t he double-sided t ape (it em #2) and
place the Sensor Plate in its place.
Press the Sensor Plate to the DataT ag such that the
double-side d tape will hold the Sensor Plate in place.
Make sure the contacts at the bottom part of the plate are
aligned with the pins in the DataTag.
Peel the paper from the three pieces of double-sided
tape: The two larger pieces (items #3 & #4) are used for holding the
DataTag to the tagged object, while the smaller piece in the middle (item
#5) is used for pulling the Sensor Plate off
the DataTag when the DataTag is removed
from the t agged object, in order to det ect the
T am p er ev ent .
4.1 Placing the DataTag on a Vehicle
Note
: The Installation instructions refer to
the case when the DataReader is installed
Vertically.
1
2
5
4
3
