Chapter 3 DataSeal Installation
Hi-G-Tek Ltd. Micro electronics & Asset Tracking Technology - 35 -
To in st all t h e Dat aSeal, ho ld t h e un it at a
45° angle as illustrated and snap it into
place in its cradle on the DataSeal
Mount ing Fixt ure. (Fig. 3)
To connect the Sealing Wire, simply attach
one end of the Sealing Wire connectors to
either of the sockets at the base of the
DataSeal (Fig. 4).
Loop t he wire t hrough t he cont ainer locking
ring and the keeper bar, then insert the end
into the other socket (Fig. 5).
