Note: old DataSeals return only the Short Status as a response to the Se t
command (as shown in Figure 7 -0 ), while newer ones (version 2.20 and
above) return Long Status an d Seal S tam p.
7.6.5 Soft Set
Similar to the Se t command, the Soft Set command is used to prepare a
DataSeals for a new use, but unlike the Se t co mm an d, th e ex ist in g E v ent
records are not deleted. For the description of the response see the Se t
command in the previous section.
This command is multi-addressed, and can be sent to up to 8 DataSeals in a
single command. You must enter between 1 and 8 Seal IDs in the
Seals/Tags ID box, one in each line, before executing the command.
7.6.6 Suspended Set
This command is also similar to the Set command, but unlike the Se t
command, the Sealing Wire can be open, and the operation completes only
afterwards, when the Sealing Wire is closed. Between the command
execution and the closing of the Sealing Wire, the Suspen de d Se t ( SS) f la g
in the Short Status is set. Only when the Sealing Wire is closed, the Event
records are deleted, the Tampered flag is cleared and a new Suspended
Se t Event record is written.
If the Sealing Wire was open at the time of the command execution, the
DataSeal's will indicate the following flags in the Status: Tampered,
Opened, and Suspende d Se t. If the Sealing Wire was closed at the time of
the command execution, the DataSeal will indicate an OK status.
