Instruction Manual

PoE Power/Video/Data UTP Transceiver User Manual
Applications
There are two kinds of transceivers, active and passive type, PoE work type have standard and highpower two kinds. According to different
transferring distance and camera load power, please refer to the system selection chart and PoE power chart:
Trans Distance
No.of
Cam
B/W Color
Max output*
PoE power
Transmitter Receiver Remarks
1 1640ft 1000ft 12V 0.75A HXVB200T/TA HXVB200R/RA PoE Passive
1 8000ft 5000ft 12V 0.17A
HXVB300T
HXVB301T
HXVB300R
HXVB301R
PoE active
4 8000ft 5000ft 12V 0.17A
HXVB300T
HXVB301T
HXVB604R 4ch PoE active
1 4590ft 2623ft 12V 0.32A
HXVB200T
HXVB200TA
HXVB300R
HXVB301R
PoE passive + active
4 4590ft 2623ft 12V 0.32A HXVB200T/TA HXVB604R 4 PoE passive + active
1 8000ft 5000ft 12V 0.8A HXVB305T HXVB305R Highpower PoE active
UTP Length 0-1000ft 1640ft 2623ft 3279ft 4000ft 5000ft 6000ft 7000ft
Standard PoE 12V 0.75A 12V 0.5A 12V 0.32A 12V 0.26A 12V 0.21A 12V 0.17A / /
Highpower PoE 12V 3.5A 12V 2.4A 12V 1.5A 12V 1.2A 12V 1A 12V 0.8A 12V 0.65A 12V 0.56A
Note: The chart test result use UTP CAT5 24AWG, and high voltage of input range AC28V/DC28V for PVD receiver.
