PoE Power/Video/Data UTP Transceiver User Manual INSTRUCTION MANUAL
PoE Power/Video/Data UTP Transceiver User Manual Summary The unit is a device that allows the transmission of real-time video and power over Unshielded Twisted Pair cable. PoE PVD transmitter convert unbalanced video signal to balanced (same range but opposite polarized) difference signal transmitting via the UTP cable, have good common interferences rejection, under strong interference environment can transmit color video in high quality.
PoE Power/Video/Data UTP Transceiver User Manual Applications There are two kinds of transceivers, active and passive type, PoE work type have standard and highpower two kinds. According to different transferring distance and camera load power, please refer to the system selection chart and PoE power chart: No.of Cam Trans Distance Max output* PoE power 1 B/W 1640ft Color 1000ft 1 8000ft 5000ft 12V 0.17A 4 8000ft 5000ft 12V 0.17A 1 4590ft 2623ft 12V 0.
PoE Power/Video/Data UTP Transceiver User Manual Applications Instruction
PoE Power/Video/Data UTP Transceiver User Manual Specifications HXVB200T/T Model A HXVB200R/R HXVB201T A 1ch video Signal Channel 1ch video HXVB300 HXVB301 T T HXVB305T HXVB408 HXVB300 HXVB301 HXVB305R R R R 1ch video 1ch video 1ch video 8ch video HXVB604R 4ch video (passive) (active) (active) 1ch audio (active) (passive) (active) 1ch power 1ch power 1ch power (active) 1ch HPower 8ch power 4ch power 1ch dat/audio 1ch data 1ch data 1ch power 1ch data 8ch data 4ch da
PoE Power/Video/Data UTP Transceiver User Manual DC36V 0.5A input power, so can use one 100W 36V/3A power adapter for 6 PoE Receiver. Transceiver setting and indication PoE PVD passive transceiver no need set gain, they have indication LED. Transmitter have power good LED, Receiver have load/unload dual color LED.
PoE Power/Video/Data UTP Transceiver User Manual Frequently Asked Question 1. What kind wire use for PoE series transceiver We recommend use 4 pair Unshielded Twisted-Pair cable, category 3 or higher, 16-24AWG, multi-pair (6 pair or more)twisted pair is ok. If use STP (shield twisted pair) cable, the modular plugs need to use shielded too, make sure STP shielded and modular plugs shielded connect together.
PoE Power/Video/Data UTP Transceiver User Manual reduce the current, there by to reduce the power consumption. Otherwise may lead to large power lost (Voltage lost=I*R) or current limit exceeded. Single 36V adapter more costs than 12V adapter, but PoE PVD transceiver is centralized power supply, one 36V 3A adapter can supply 6 pairs of PoE PVD transceiver, one transceiver need 0.5A power only. Averagely ,each pair transceiver adapter cost not higher than 12V adapter. 5.
PoE Power/Video/Data UTP Transceiver User Manual 4. What cause about image twist and wobble UTP RJ45 connector order mistake, please as RJ45 jack instruction connect. 5. The image to bright and white twist The video signal too strong, please adjust sharpness DIP switch and birghtness of PVD receiver, and set to lower signal grade. 6.
