HXJZ-882 Micro Power Wireless Module User’s Manual
Trouble and solve ways:
NO.
Trouble
Trouble causes and solve ways
1
No shine of
Indicator light
a、Power Line badness touch .
b、Power is bad.
c、Power line meet in reverse, or diode of polarity protect is bad.
2
No transmit
or
No receive
a、Radio is badness touch with PC/terminal.
b、Radio with TTL/RS232/RS485 not match terminal.
c、RX frequency and TX frequency is not same.
3
Bit error rate
High
a、antenna not match, or touch bad;
b、RF baud rate is not right. c、
Power supply ripple is too great.
4
Indicator light
twinkling
a、Electromagnetism disturb in circumstance.
b、Same frequency disturb in the circumstance.
