HXJZ-882 Micro Power Wireless Module User’s Manual
Channel and frequency list
Channel
Frequency
Channel
Frequency
1
487.5072MHZ
5
490.6942MHZ
2
488.4289MHZ
6
491.1580MHZ
3
489.2329MHZ
7
491.7360MHZ
4
489.9260MHZ
8
492.4388MHZ
Technical specification of HXJZ-882
Modulation mode: GFSK
Working frequency: 487--493MHZ
Transmission power: <500mW
Receiving sensitivity: -120dBm
Transmitting current:: <400mA
Receiving current: <60mA
Sleeping current: <10mA
Channel speed rate: 1200/2400/4800/9600/19200Bit/s, User can Choose one
Interface speed rate: 1200/2400/4800/9600/19200Bit/s, User can Choose one
Change time for receiving and sending: <10ms
Interface data format: 8E1/8N1/8O1
Power supply: 5±0.5V DC
Working temperature: -20℃～85℃
Working humidity: 10%～90% relative humidity without condensation
Dimension: 63 mm*43mm*15 mm
Attachable Communication with Model: JZ881/HXJZ-882
Model and name
JZ
882
-T
T: TTL interface
2: 232 interface
4: 485 interface
Products Item
Company logo
Optional Antenna:
