Datasheet

3.6
324
Further information at www.HellermannTyton.com/protection
Date of issue: October 2015
Cable Protection Systems
Protective Sleeves
MATERIAL
Polyester (PBT)
Operating Temperature -50 °C to +150 °C, intermittent +200 °C
Melting Point +225 °C
Flammability UL94 V0, FMVSS 302
Specifications NF F 16-101, UL-Recognised
Helagaine HEGPV0X is especially suitable for areas wherever fire
protection is important as well as a higher expansion ratio of the
braided sleeve. Helagaine HEGPV0X offers superior cable protection for
machine tools, robotics and automatic equipment. Helagaine HEGPV0X
had been successfully tested to DIN5510-2 and NF F 16-101 and can
thus be used in many railway applications.
Features and Benefits
• Made of sturdy polyester
• Self-extinguishing according to UL94 V0 for enhanced fire protection
• Highly flexible
• Expansion ratio of 3:1
• Easy to apply over irregular shapes
• Good abrasion resistance
Polyester braided sleeving, expansion rate: 3:1,
UL94V0 classification
Helagaine HEGPV0X braided sleeving.
Helagaine HEGPV0X
TYPE
Bundle
Ø min.
Bundle
Ø max. Colour
Reel
Length Article-No.
HEGPV0X03 2.0 6.0 Black with White Identification Yarn (BKIDWH) 200 m 170-50030
HEGPV0X06 3.0 10.0 Black with White Identification Yarn (BKIDWH) 200 m 170-50060
HEGPV0X09 5.0 16.0 Black with White Identification Yarn (BKIDWH) 100 m 170-50090
HEGPV0X12 6.0 19.0 Black with White Identification Yarn (BKIDWH) 100 m 170-50120
HEGPV0X20 12.0 32.0 Black with White Identification Yarn (BKIDWH) 100 m 170-50200
HEGPV0X30 19.0 45.0 Black with White Identification Yarn (BKIDWH) 50 m 170-50300
HEGPV0X40 32.0 70.0 Black with White Identification Yarn (BKIDWH) 50 m 170-50400
HEGPV0X50 38.0 76.0 Black with White Identification Yarn (BKIDWH) 50 m 170-50500
All dimensions in mm. Subject to technical changes.
Colour grey available on request. Cuts in any lengths. Minimum Order Quantity (MOQ) may differ from package content.
To prevent fraying, the sleeve
can be cut with the hot cutting
tool HSG0. See page 533.
For product specific approvals and specifications please refer to the Appendix.
