Datasheet

3.6
325
Further information at www.HellermannTyton.com/protection
Date of issue: October 2015
For product specific approvals and specifications please refer to the Appendix.
Cable Protection Systems
Protective Sleeves
MATERIAL
Polyamide 6.6 (PA66)
Operating Temperature -60 °C to +150 °C, intermittent +200 °C
Melting Point +255 °C
Flammability UL94 V2, FMVSS 302
Specifications EN 45545: 2013
Helagaine HEGPA66 is particularly suitable for vehicle manufacturing as
well as plant construction.
Features and Benefits
• Made from heavy-duty polyamide yarn
• Excellent abrasion resistance
• Highly flexible
• Easy to apply over irregular shapes
• Eases application by expanding when compressed
• Very high surface covering
Polyamide braided sleeving for excellent
abrasion resistance
Various types of Helagaine braided sleeving.
Helagaine HEGPA66
TYPE
Bundle
Ø min.
Bundle
Ø max. Colour
Reel
Length Article-No.
HEGPA6604 3.0 6.0 Black (BK) 200 m 170-40400
HEGPA6606 4.0 8.0 Black (BK) 100 m 170-40600
HEGPA6608 5.0 10.0 Black (BK) 100 m 170-40800
HEGPA6610 7.0 12.0 Black (BK) 100 m 170-41000
HEGPA6612 8.0 14.0 Black (BK) 100 m 170-41200
HEGPA6616 12.0 18.0 Black (BK) 50 m 170-41600
HEGPA6620 15.0 23.0 Black (BK) 50 m 170-42000
HEGPA6625 18.0 28.0 Black (BK) 50 m 170-42500
HEGPA6630 25.0 32.0 Black (BK) 50 m 170-43000
HEGPA6640 30.0 44.0 Black (BK) 50 m 170-44000
HEGPA6650 40.0 55.0 Black (BK) 50 m 170-45000
HEGPA6660 50.0 65.0 Black (BK) 50 m 170-46000
All dimensions in mm. Subject to technical changes.
Colour grey available on request. Cuts in any lengths. Minimum Order Quantity (MOQ) may differ from package content.
To prevent fraying, the sleeve
can be cut with the hot cutting
tool HSG0. See page 533.
