Data Sheet

MATERIAL DATASHEET HelaTape Tex
Description : PE-coated cloth, coated with a rubber based adhesive.
Non-reflective mat backing.
Application : identification, protection, marking, fixing, patch & repair
Technical Data
Material : stabilised PE-coated cotton cloth
Colour : blue, red, white, yellow, green, black, grey
Thickness (carrier) : 0.20 mm
Total thickness : 0.31 mm
Core Ø
: 76 mm
Adhesive base : rubber
Peel adhesion : 3 N / 10mm
Shear adhesion : 2 h / 23°
Unwind resistance : 3 N / 10 mm
Tensile strength : 64 N / 10mm
Elongation : 10 %
Temperature resistance : -30°C up to +80°C (1h)
UV-resistance : limited
Weather resistance : good
Storage life : 24 month
HellermannTyton GmbH
Grosser Moorweg 45 Telefon: [phone]
D-25436 Tornesch Telefax: +49 (0) 4122/701-400
Data in this table represent average test results and not to be used for specification purposes.
The product user should make his/her own test to determine the product's suitability for the intended use
PM.01/12.04.12_MW
