User Manual

1/18th SCALE 4x4
ELECTRIC MONSTER TRUCK
...TRANSMITTER CONTINUED...
#
5
Standard operaon:
• Turning the transmier wheel to the le from center makes the wheels on the vehicle turn LEFT
• Turning the transmier wheel to the right from center makes the wheels on the vehicle turn RIGHT
• Pulling the transmier trigger back towards the handle will make the vehicle accelerate forward
• Pushing the transmier trigger forward away from the handle will have the following aects depending
on the locaon of the trigger prior to pushing it forward
› From a stop at neutral: the vehicle will travel in reverse
› From pulled back: the vehicle will apply brakes to slow the speed
» A second push forward of the trigger will apply reverse throle
» WARNING: Causing the vehicle to make quick transions from forward/reverse moon to
the opposite direcon using the throle control can cause damage to your vehicle and will
void the warranty
Using your transmier for the rst me:
1. Turn the transmier ON and ensure the LED is lit SOLID indicang the baeries are supplying adequate
voltage for proper operaon
2. Seng the throle trim
a. If the wheels spin in a forward direcon when the trigger is in the neutral posion, turn down the
trim unl the motor stops
b. If the wheels spin in a reverse direcon when the trigger is in the neutral posion, turn up the trim
unl the motor stops
c. There will be a “dead band” area where the trim can be adjusted a slight amount in either
direcon and the wheels will not begin to move. It is ideal to have the trim set in the middle of this
“dead band”
3. Seng the steering trim
a. With your vehicle and transmier turned on (and properly responding to transmier inputs), set
the vehicle down on the ground and slowly accelerate in a direcon directly away from you. If the
vehicle veers slightly either to the le or right, stop the vehicle and adjust the Steering Trim knob
in the opposite direcon of the veer in small increments
b. Reset the vehicle and re-test; adjust the trim as needed unl the vehicle travels in a straight line
while the transmier wheel remains at center locaon (“hands-o”)
[PULL]
FORWARD
THROTTLE
[PUSH]
REVERSE
THROTTLE
TURN LEFT
TURN RIGHT
PAIR/BIND/ESC SET BUTTON
LED INDICATOR
ON/OFF
SWITCH
LOW VOLTAGE CUT-OFF
