User Manual

UNDERSTANDING YOUR TRANSMITTER...

Features:

1. Steering wheel: controls le/right moon (designed to be operated with right hand)

2. Throle trigger: controls forward/reverse moon (designed to be operated with le index nger)

3. Handle: For holding the transmier (designed to be held with le hand)

4. Antenna: Transmits signal to the receiver located in the vehicle

5. Control panel cover: Covers control panel housing radio seng controls

6. ON/OFF Switch: Turns the power ON/OFF for the transmier

7. Indicator lights: Mulfuncon Green LED

a. Solid Green: Adequate baery voltage for proper operaon

b. Flashing Green: Low baery voltage warning, baeries should be replaced/recharged before

connued use

8. Pair/Bind buon: Used for Pairing/binding the transmier to the receiver

9. Steering Trim: Controls the “hands-o” le/right direcon of the vehicle

10. Throle Trim: Adjusts the motor speed to STOP when trigger is in “hands-o” (neutral) posion

11. Steering Dual Rate (D/R): Adjust the total throw of the steering travel

12. Baery compartment: houses [8] AA baeries for powering the transmier

13. Boom cover: Closes the baery compartment, containing the AA baeries

Baeries:

WARNING: Do not aempt to charge non-rechargeable baeries

• Remove the lower door from the transmier to access the baery compartment

• Install [8] AA type baeries into the compartment

› Pay close aenon to baery polarity (+/-) indicators during installaon

• Never mix brands or old/new baeries

• Always remove dead baeries from the transmier

• If using rechargeable baeries, be sure to follow the manufacturer’s care and use instrucons

• Rechargeable baeries must be removed from transmier before charging

• Always be sure to be responsible and protect the environment when disposing baeries. Your local

hobby dealer provides a FREE baery disposal service
