TABLE 2

HYSICAL AND ELECTRICAL DATA TABLE (RSG)

Condensing Unit 078 090

Operating Weight (lbs.) [kg] 264 [119.8] 287 [130.2]

Shipping Weight (lbs.) [kg] 283 [128.9] 306 [138.8]

COMPRESSOR:

Quantity 11

Type Scroll

RPM 3500

CONDENSER FANS:

Quantity 11

CFM [L/s] 4700 [2218] 4700 [2218]

Diameter (in.) [mm] 24 [610] 24 [610]

Motor Horsepower (ea.) [W]

⁄3 [249]

Type PSC PSC

RPM 1075 1075

CONDENSER COIL:

Quantity 11

Rows 1

⁄2 2

Fins per Inch 20 22

Square Feet [m2] 22.2 [3] 22.2 [3]

Fins/Tubes Aluminum/Copper

Tube Size, O.D. (in.) [mm]

⁄8 [10]

ELECTRICAL DATA TABLE (RSG)

MODEL NO. RSG 078A3 078A4 078A5 090A3 090A4 090A5

COMPRESSOR MOTOR:

Electrical Characteristics 208/230-3-60 460-3-60 575-3-60 208/230-3-60 460-3-60 575-3-60

OPERATING CURRENT:

Rated Load Amps 22.4/22.4 10.6 7.0 25/25 12.2 9.0

Locked Rotor Amps 149 75 54 164 100 78

CONDENSER FAN MOTORS:

Volts & Phase 208/230-1 460-1 575-1 208/230-1 460-1 575-1

Full Load Amps (each) 2.2 1.3 1.0 2.2 1.3 1.0

SYSTEM CHARACTERISTICS:

Unit FLA 25.0 12 8.0 28.0 14.0 10.0

Minimum Circuit Ampacity 31/31 15 11.0 34/34 17 13

Max. Fuse Size or HACR

Circuit Breaker Ampacity 50/50 25 15 50/50 25 20

Disconnect Size 60 30 30 60 30 30

VII. INSTALLATION

A. IMPORTANT MESSAGE TO OWNER

The manufacturer assumes no responsibility for equipment installed in violation of any

code or regulation. The operation portion of this manual gives instructions as to the ser-

vice and care of the unit. It is recommended that the installer go over the operational

portion of this manual with the owner so that there is a full understanding of the equip-

ment and how it is intended to function.

These instructions should be read and kept for future reference. It is suggested that this

booklet be affixed to or adjacent to the indoor equipment. It is addressed to your dealer

and serviceman, but we highly recommend that you read it—paying particular attention

to the section titled “MAINTENANCE.”

B. INSPECTION AND HANDLING

Inspect exterior of unit for evidence of rough handling in shipment. If damage is found,

enter claim at once. Unpack carefully after moving unit to approximate location. Any

damage should be reported immediately to the transportation company.

Material in this shipment was inspected at the factory and released to the common carri-

er with no known damage.

NOTE: N.E.C., C.E.C. and local codes take precedence over suggested wire and fuse sizes.

[ ] Designates Metric Conversion
