User Guide

Page 44
7019-205C
September 1, 2008
R
Santa Fe Pellet Insert
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on the Quadra-Fire web
site at www.quadrafire.com. When ordering, supply serial and model numbers to ensure correct service parts.
D. Service Parts and Accessories
Item No. Service Parts, Alphabetical Order Part No.
14 Access Panel Left and Right (interchangeable) 7019-025
38 Ash Drawer 7019-006
12 Baffle Assembly UK-30KPEL
Bearing, Feed System, Nylon 410-0552
18 Blower, Exhaust with Housing & Gasket 812-4400
21 Blower, Convection, Motor Only with Spade Terminals & Magnet 812-4900
11 Brick, Cast Left & Right Sides (interchangeable) 414-0270
43 Brick, Cast, Center 414-0260
Component Pack
(includes firepot clean-out tool, power cord with terminal, thermostat har-
ness & manual, hose grommet, warranty card, owner’s manual and “How-To-Operate” DVD)
.
7019-010
26 Control Box, 3 speed SRV7000-205
40 Door Assembly 7019-013
39 Door Hinge Assembly SRV7019-014
2 Door Handle, Black Nickel 7019-174
4 Door Latch Assembly 7019-015
3 Door Pin 3/16 x 1/2 7000-229
Door Handle Assembly (includes handle, set screw & pin) SRV7019-037
19 Exhaust Transition Assembly 414-5100
36 Face Assembly 7019-028
30 Face, Left Side SRV7019-117
13 Face, Right Side SRV7019-116
33 Face, Top 7019-030
23 Feed Motor Bracket 7001-039
22 Feed Motor with Capacitor 812-4421
24 Feed Spring Assembly SRV7001-046
Firepot Clean-Out Tool 414-1140
42 Firepot, EZ Clean SRV414-5200
5 Firepot Pull Rod, Black Nickel 7019-009
20 Flue Collar Assembly 7019-031
Fuse, 7 amp, Junction Box 812-0380
Fuse, .8 amp, Control Box 812-3780
Gasket, between center brick firebox 842-2350
Gasket, Tadpole, 10 feet, Door 842-5130
Gasket, Firepot 240-0930
Gasket, Flue Collar 240-0850
41 Glass Assembly with Gasketing (Tape) 7001-038
34 Grille Bar, Upper, for Scraper Rod, 1 piece see page 42
35 Grille, Upper, Assembly, 3 pieces see page 42
37 Grille, Lower, Assembly, 4 pieces see page 42
Grille Bracket Covers, order quantity needed 7019-199
Heat Output Control Switch (Rocker Switch) 812-3500
31 Hopper Lid 7019-145
