092366D RevB Sense and Dispense CO2 Dispense Kit for Aqua Rite Pro and Pro Logic ..... Owner's Manual Contents Description............................1 Installation............................2 Warranty................................6 AQL-CHEM2 AQL-CHEM2-240 Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 Phone: (908) 355-7995 www.hayward.
Description The AQL-CHEM2 is a 120 VAC CO2 dispense kit designed for use with a Hayward Aqua Rite Pro chlorinator or Pro Logic pool control. The AQL-CHEM2-240 is identical to the AQL-CHEM2, but uses 240 VAC. When used with the AQL-CHEM sensing kit, the AQL-CHEM2(-240) solves the problem of how to provide low cost pH control for backyard pools without having to handle acid. The AQL-CHEM2(-240) is designed to install on a standard CO2 tank and wire directly to the Aqua Rite Pro or Pro Logic.
Installation Installation Installing the AQL-CHEM2 or AQL-CHEM2-240 requires the following steps: • Mount CO2 tank using commercially available straps • Attach the solenoid valve to the CO2 tank • Install the PVC check valve injector to the pool's return plumbing • Plug the solenoid valve into the pigtail of the Aqua Rite Pro or Pro Logic pool control • Configure the Aqua Rite Pro or Pro Logic to control the AQL-CHEM2(-240) This manual assumes that the Hayward AQL-CHEM Chemistry Kit and the pH Dispense Pi
Installing the PVC check valve When installing the PVC check valve, refer to the plumbing overview of the AQL-CHEM and AQL-CHEM2(-240) shown below. The PVC check valve must be installed at the pool's return line DOWNSTREAM of the electrolytic cell and flow switch. Because mild acid will be dispensed at this location, it should be the last component installed in the return line before water is allowed to flow back to the pool.
4 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
5 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
LIMITED WARRANTY (effective 03/01/12) Hayward warrants its Pro Logic, OnCommand and E-Command pool automation products as well as its Aqua Rite, Aqua Rite Pro, Aqua Plus and SwimPure chlorination products to be free of defects in materials and workmanship, under normal use and service, for a period of three (3) years. Hayward also warrants its Aqua Trol chlorination products to be free of defects in materials and workmanship, under normal use and service for a period of one (1) year.
For further information or consumer technical support, visit our website at www.hayward.com Hayward is a registered trademark and Aqua Rite Pro and Pro Logic are trademarks of Hayward Industries, Inc. © 2016 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
