2-5
RF-7800B
SYSTEM SETUP AND TEARDOWN
R
Figure 2-4. Opening the USIM Card Holder on RF-7800B-DU024
Figure 2-5. Placing the USIM Card in Holder on RF-7800B-DU024
Figure 2-6. USIM Card Located in Holder on RF-7800B-DU024
CL-0365-4200-0007
UNLOCKED POSITION
CL-0365-4200-0008
ANGLED EDGE
OF USIM CARD
GOLD CONTACTS
ON THIS SIDE
CL-0365-4200-0009
LOCKED POSITION
