2.0 Technical Information
2.1 Specifications
2.1.1 Product Code for MCR Trolley Alone:
2.1.2 Product Code for MCR Air Trolley with TCR Series Air Hoist:
Table 2-1 Trolley Hoist Specifications
TCR Lifting/Lowering Speeds
(ft/min)
TCR Air Consumption Rates
(cubic ft/min)
90 psi Lifting / Lowering
90 psi Lifting / Lowering
TCR MCR
Cap.
(Tons)
MCR Product
Code TCRM
Product
Code
Standard
Lift
(ft)
Push
Button
Cord
L
(ft)
No Load w/Rated Load
90 psi
Traversing
Speed
(ft/min)
No Load
w/Rated
Load
No Load
&
w/Rated
Load
MCR
Flange Width
A
djustability
B
(in)
MCR
Minimum
Allow.
Radius
for Curve
(in)
TCR
Load Chain
Diameter
(mm)
x
Chain Fall
Lines
Net
Weight
(lbs)
Weight for
A
dditional
One Foot
of Lift
(lbs)
1/4 TCRM250P
1/2 TCRM500P
68 / 44 37 / 57 137.8 6.3 x 1 170 0.6
1 TCRM1000P2 34 / 22 18.5 / 28.5
63 / 49 48/57
6.3 x 2 183 1.2
1
MCR1000
TCRM1000P 37 / 22 21 / 33
2.28 to 5.00
31.5
7.1 x 1 209 0.75
2 TCRM2000P2 18.5 / 11 10.5 / 16.5
62 / 53 53/60
51.2
7.1 x 2 1.5
3
MCR3000
TCRM3000P 18 / 11 10 / 14.5
3.94 to 6.02
31.5
11.2 x 1
254
2.0
6 MCR6000 TCRM6000P2
10 7.4
9 / 5.5 5 / 7.5
65
90 / 65 71/74
53
4.92 to 7.02 78.7 11.2 x 2 364 4.0
2.1.3 Operating Conditions and Environment
Temperature Range: +14° to +140°F (-10° to +60°C)
Humidity: 85% or less
Supply Air: 60 or 90 psi
