Manual

9.3 Air Connection and Pendant Parts
49
Fig.
No.
Description Qty.
TCRM250P
TCRM500P
TCRM1000P2
TCRM1000P
TCRM2000P2
TCRM3000
TCRM6000
1 Tube Fitting 2 MCR135106105
2 Tube Fitting 1 MCR135106101
3 Pipe Adapter 1 MCR134706040
4 Elbow 1 MCR135102004 MCR135101004
5 Nipple 1 MCR135004004
2 TCR1350005HH
6 Hose Stem Assembly
1 TCR420845DHH
7 Nipple w/Screen 1 MCR41000136B
8 Hose Nut 1 MCR135600101
9 Hose Stem 1 MCR134800101
10 Hose 1 MCR137202009 MCR137202017
11 Hose Clamp 2 MCR137501021 MCR137501026
12 Hex Socket Pipe Plug 1 MCR134902001
13 Pendant Complete Set 1 60721
14 Pendant Handle Complete 1 TCR420240VBC
15 Washer 3 9012510
16 Socket Bolt 2 9091226
17 Pendant Bracket 1 60709
18 Tube Fitting 5 MCR135106102
19 Straight Fitting 2 9008105
20 Under Cover 1 60710
21 Socket Bolt 1 9091229
22 Nut 1 9093417
23 Cable Tie 1 9006602
24 Warning Tag 1 WTAG7
25 Cable Crimp 2 9013121
26 Strain Relief Cable FT 9013120
27 Conduit FT 9008303
28 Tubing - Black FT 9013114
29 Tubing - Yellow FT 9013138
30 Tubing - Green FT 9013139
31 Tubing - Clear FT 9013116
32 Tubing - Red FT 9013115
