9.1 Side Plates, Gearbox and Suspension Parts
44
Fig.
No.
Description Qty. MCR1000 MCR3000 MCR6000
Capacity Name Plate ¼ Ton 6072503
Capacity Name Plate ½ Ton 6072501
Capacity Name Plate 1 Ton MCR137301041
Capacity Name Plate 2 Ton 6072502
Capacity Name Plate 3 Ton MCR137301043
101
Capacity Name Plate 6 Ton
1
MCR137301046
102 Socket Bolt 4 9091203
103 Name Plate 1 MCR137301049
104 Rivet 4 MCR133001110
113 Balance Weight 1 MCR422610950
114 Balance Weight Washer 4 MCR422610970
115 Socket Bolt 4 9091282 9091283 9091284
Suspender TCR250, 500 & 1000 6040201
Suspender TCR1000-2 60403
Suspender TCR2000-2 6040401
Suspender TCR3000 MCR422630330
116
Suspender TCR6000
1
MCR422770350
Hanger TCR250, 500 & 1000 MCR422695550
Hanger TCR1000-2 MCR422710550
Hanger TCR2000-2 MCR422740550
Hanger TCR3000 MCR422755550
117
Hanger TCR6000
1
MCR422770550
Socket Bolt
TCR250, 500, 1000-2,
1000 & 2000-2
9091269
118*
Socket Bolt
TCR3000 & 6000
1
9091271
123 Hanger Bracket 1 MCR422610600 MCR422630610 MCR42266065B
124 Socket Bolt 3 9091273 9091274
125 Nut 3 9093424
126 Spring Washer 3 9012711
Socket Bolt
TCR250, 500, 1000-2,
1000 & 2000-2 2
9091271
127*
Socket Bolt
TCR3000 & 6000
1
9091272
128 Split Pin 1 9009423
*Use Socket Bolt figure no. 127 in place of no. 118 when optional chain container is installed on hoist.
