9.1 Side Plates, Gearbox and Suspension Parts
43
Fig.
No.
Description Qty. MCR1000 MCR3000 MCR6000
1 Track Wheel "G" Assembly 2 MCR422610010 MCR422630010 MCR422660010
2 Track Wheel "S" Assembly 2 MCR422610020 MCR422630020 MCR422660020
3 Bearing 4 9000702 9000705 9000708
4 Retaining Ring 4 9047242 9047262 9047290
5 Side Plate "G" Assembly 1 MCR42261003B MCR42263003B MCR42266003B
6 Side Plate "S" Assembly 1 MCR42261006B MCR42263006B MCR42266006B
7 Retaining Ring 4 9047115 9047125 9047140
9 Wheel Washer 4 MCR422610090 MCR422630090 MCR422660090
10 Side Roller 4 MCR422610100 MCR422630100 MCR422660100
11 Side Roller Shaft 4 MCR422610110 MCR422630110 MCR422660110
12 Side Roller Holder 4 MCR422610120 MCR422630120 MCR422660120
13 Stopper Plate 4 MCR422610130 MCR422630130 MCR422660130
14 Socket Bolt 4 9091272 9091294 90913150
15 Spring Washer 4 9012711 9012712 9012715
16 Suspension Shaft 1 MCR422610700 MCR422630700 MCR422660700
17 Bolt 1 MCR422610170 MCR422630170 MCR422660170
18 Slotted Nut 1 T3P154020 T3P154050 T3G154075
19 Split Pin 1 9009414-5 9009423 9009436
20 Shaft Stopper Pin 1 MCR422610200 MCR422630200 MCR422660200
21 Split Pin 1 9009432 9009444
22 Thick Spacer (x) MCR422610210 (5) MCR422630210 (3) MCR422660210 (3)
23 Thin Spacer 8 MCR422610710 MCR422630710 MCR422660710
24 Bumper 4 MR1DS9631 MR1FS9631
25 Spring Washer 4 9012711
26 Nut 4 9093424
27 Bumper Bracket 4 MCR422612750 MCR422632750 MCR422662750
28 Spring Washer 8 9012711 9012712 9012715
29 Socket Bolt 8 9091272 9091295 90913151
30 Gear Case 1 MCR422610220
31 Bearing 2 9000605
32 Retaining Ring 1 9047252
33 Spring Pin 2 91481113
34 Drive Gear 1 MCR422610230 MCR422630230 MCR422660230
35 Retaining Ring 1 9047125
36 Gear 1 MCR422610240
37 Gear Spacer 1 MCR422610250
38 Socket Bolt 4 9091294 9091295
39 Spring Washer 4 9012712
40 Gear Case Packing 1 MCR136102099
41 Gear Cover 1 MCR422610270
42 Bearing 2 9000505
43 Socket Bolt 2 9091277
44 Socket Bolt 2 9091272
45 Spring Washer 4 9012711
46 Pinion 1 MCR422610280
47 Retaining Ring 1 9047125
48 Socket Bolt 4 9091272
49 Square Spacer 4 MCR131411010 MCR131411030 MCR131411060
