EQ SETTINGS
The JBL OnBeat Xtreme dock has five equalizer (EQ) modes that adjust
the tone quality to suit different types of programs: Music (default),
Movies, Internet Radio, Chat, or Games, in that order.
Use the remote control to change the EQ setting for the active source:
1. Press and hold the Enter button on the remote control. The EQ will
advance to the next setting (Movies) and the Source Select LED will
flash to indicate that the EQ setting has advanced.
2. Each press-and-hold of the Enter button advances the EQ to the next
mode: Movies, Internet Radio, Chat, and Games. The Source Select
LED will flash each time the EQ advances.
3. When the Source Select LED flashes twice, the EQ has returned to
Music mode.
POWER AND SOURCE SELECT LEDS
The Power LED color changes to indicate the state of JBL OnBeat
Xtreme unit.
Power LED Color State
White – Constant JBL OnBeat Xtreme unit is on.
White – Flashing JBL OnBeat Xtreme unit is muted.
Amber – Constant JBL OnBeat Xtreme unit is in sleep mode.
Amber – Flashing JBL OnBeat Xtreme unit is in software upgrade mode.*
No LED JBL OnBeat Xtreme unit is off.
The Source Select LED color changes to indicate which source is active.
Source Select
LED Color
State
White – Constant iPod/iPhone/iPad dock is the active source.
White – Quick Flash Once EQ for iPod/iPhone/iPad is changed to Movies,
Games, Chat, or Internet Radio mode.
White – Quick Flash Twice EQ for iPod/iPhone/iPad is changed to Music
mode.
White – Flash Once Video is switched on.
White – Flash Twice Video is switched off.
Blue – Constant Bluetooth-enabled device is the active source.
Blue – Flashing Bluetooth-enabled device is in Pairing mode.
Blue – Quick Flash Once EQ for the Bluetooth-enabled device is changed
to Movies, Games, Chat, or Internet Radio mode.
Blue – Quick Flash Twice EQ for the Bluetooth-enabled device is changed
to Music mode.
Amber – Constant Auxiliary input device is the active source.
Amber – Quick Flash Once EQ for the auxiliary input device is changed to
Movies, Games, Chat, or Internet Radio mode.
Amber – Quick Flash Twice EQ for the auxiliary input device is changed to
Music mode.
*If the Power LED and the Source Select LED are both flashing amber
slowly, the software upgrade failed.
