Item 69897
SAFETY OPERATION MAINTENANCEASSEMBLY
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY
REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Parts List
Part
Description
Qty
1
7/32" Safety Chain
1
2
Hitch Coupler
1
3
Coupler Base
1
4
Drawbar T-Plate
1
5
Drawbar Rail
2
6
Drawbar Bracket
2
7
Bolt M10
x
30
4
8
Leaf Spring
2
9
Fender Bracket
2
10
Spring Plate
2
11
Axle
1
12
Hub Assembly
2
13
5.30-12" Tire
2
14
Dust Cap
2
15
Front Left Side Rail
1
16
Bolt M12
x
75
6
17
Left Spring Hanger
1
18
Fender
2
19
Flat Washer Ø22
2
20
Rear Left Side Rail
1
21
Cross Member
5
22
Rear Right Side Rail
1
Part
Description
Qty
23L
Left Tail Light
1
23R
Right Tail Light
1
24
Light Bracket
2
25
Carriage Bolt M10
x
25
4
26
Right Spring Hanger
1
27
Front Right Side Rail
1
28
Front Member
1
29
Bolt M12
x
25
2
30
L-Latch Ø12
x
75
2
31
Bolt M10
x
20
48
32
U-Bolt M10
x
90
4
33
Nut M10
64
34
3mm R-Clip
2
35
Nut M12
8
37
Castle Nut M22
x
1.5
2
38
Cotter Pin
2
39
Bearing
4
40
Lug Nut M12
10
43
2mm R-Clip
1
44
License Plate Bracket
1
45
Side Running Light
2
46
Screw M4 x 25
4
47
Locking Pin
1
Record Product’s Serial Number Here:
Note:
If product has no serial number, record month and year of purchase instead.
If product has no serial number, record month and year of purchase instead.
Note:
Some parts are listed and shown for illustration purposes only,
Some parts are listed and shown for illustration purposes only,
and
are not available individually as replacement parts.
