WIRE LEAD
FROM
SIDE RUNNING LIGHT
SIDE RUNNING LIGHT
(45)
WHITE GROUND WIRE
WHITE GROUND WIRE
WIRE LEAD
FROM
SIDE RUNNING LIGHT
(45)
BROWN
BROWN
YELLOW
GREEN
BROWN
BROWN
YELLOW
YELLOW
YELLOW
BROWN
BROWN
BROWN
GREEN
GREEN
BROWN
BROWN
LEAVE 16" EXCESS WIRE HERE.
LEAVE 16" EXCESS WIRE HERE.
LEAVE 16" EXCESS WIRE HERE.
LEAVE 16" EXCESS WIRE HERE.
LEFT TAIL LIGHT (23L)
RIGHT TAIL LIGHT (23R)
WIRE HARNESS CONNECTOR PLUG
Figure
I:
Trailer Wiring
