Page 4For technical questions, please call 1-800-444-3353.SKU 68283
22. Note: “P50” will be the most recent saved
setting while “P01” will be the oldest.
23. If the torque setting is exceeded by 125% of the full
scale, the LED will ash RED and the alarm will beep.
24. WARNING! Do not press the Memory and
Power buttons at the same time. This will
calibrate the tool and alter the preset values.
25. To turn off the Adapter, press the Power button OR wait
80 seconds for the Adapter to turn off automatically.
26. Clean, then store the tool indoors
out of children’s reach.
Maintenance and Servicing
Procedures not specically explained
in this manual must be performed
only by a qualied technician.
Replacing Batteries
1. NOTE: When battery power is low, a “ ” icon
will appear on the display screen. Battery life will
depend on battery quality and amount of hours
tool is used. Typical battery life is 110 hours.
2. To replace battery, remove Battery Cap.
3. Remove old battery.
4. Install new CR2032 button cell battery, making sure to
follow indicated polarity (the “+” should face upwards).
5. Replace Battery Cap.
6. Remove the battery if Torque Adapter
will be stored for a long time.
Cleaning, Maintenance,
and Lubrication
1. BEFORE EACH USE, inspect the general condition
of the tool. Check for loose hardware, misalignment
or binding of moving parts, cracked or broken
parts, damaged electrical wiring, and any other
condition that may affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Do not use cleaning agents to clean the plastic parts
of the tool. Use only a mild detergent or a damp
cloth. Do not let water come into contact with tool.
Part Description Qty.
1 Upper Housing 1
2 Control Panel 1
3 Display Panel 1
4 LED 1
5 Circuit Board 1
6 Adapter 1
7 Ratchet Gauge 1
Part Description Qty.
8 Buzzer 1
9 Lower Housing 1
10 Screw 10
11 Battery Holder 1
12 Battery 1
13 Battery Cap 1
Parts List
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS
TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES
ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
