User's Manual

18 · Appendix
Specifications
Wireless Camera
Image Sensor Type 1/4” Color CMOS Image Sensor
Effective Pixel H: 1280, V: 1024
Resolution
High : 2.5 Mbps(1280x720@~15fps), Middle : 1.5Mbps(704x480
@~20fps), Low : 700Kbps(704X480@~ 10 fps)
Image Compression MPEG4
Max.Framerate 20fps @704x480
Streaming Capability Uni
IP IPv4
Protocol UDP, RTSP, NTP, DHCP, HTTP
Streaming Method Unicast
Max. User Access 4 Users simultaneously
White Balance Auto
Item Details
Lens EFL=3.95mm, F=2.2
Viewing Angle (Diagonal) 55 degree
IR LED Type/ Night Vision IR LED – 940nm /5m
Lullabies 4 songs (Monitor Remote On / Off)
Night Light Yes (Manual & Remote On/Off) (Amber color, 3000-3500K)
Loud Speaker Output 0.5W, 90dB spl
Power Requirement DC 5V ± 10%
Power Consumption 4.5Watt (Normal)，6.0Watt(IR On)
VOX level detection Low: 50dBA / High: 60dBA
Operating Temperature Range 0°C~+40°C
Operating Humidity Range 85% RH
Environment Rating Indoor use only
Pan Angle 300°
Panning/tilt Speed 12 degree per sec.
Tilt Angle
110°
Regulation Compliance FCC/CE/IC (Canada certification)
RoHS Compliance Yes for CE version only
Audio Built in Microphone/ Speaker
Weight 256g
Wireless Monitor
Display Type/Size Color TFT 5”
Resolution 800X480
Touchscreen Resistive touch type
SD card slot Yes (Micro SD / not included)
Digital Zoom X1.5, x2
Real Time Clock (RTC) +/- 4sec / day
a
