Computer Monitor User Manual

User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 19.0"
LCD Panel
Pixel pitch 0.2835mm(H) x 0.2835mm(V)
H-Frequency 30KHz – 80KHz
Video
V-Frequency 55 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1440 x 900 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode ≤42W
Power Saving Mode ≤1W
EPA ENERGY STAR
®
OFF Mode ≤1W
Audio output Rated Power 1.0W rms (Per channel)
Input Terminal
VGA
DVI
Maximum Screen Size
Hor. : 428mm
Ver. : 278mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 50°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 80%
Dimensions
443 (W) x 381.5(H) x 200(D) mm
17.5 ”(W)×15.1 ”(H)×8.0 ”(D)
Weight (NW) 4.5 kg
***The above specification is subject to actual product specification and is subject to change without
prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
22
