ERROR MESSAGE & POSSIBLE SOLUTIONS
 CABLE NOT CONNECTED :
1. Check that the signal-cable is properly connected, If the connector is loose, tighten the
connector’s screws.
2. Check the signal-cable’s connection pins for damage.
 INPUT NOT SUPPORT :
Your computer has been set to unsuitable display mode, set the computer to display mode given
in the following table.
FACTORY PRESET TIMING TABLE:
MODE RESOLUTION
HORIZONTAL
FREQUENCY (KHz)
VERTICAL
FREQUENCY (Hz)
1 720×400 @70Hz 31.469 70.087
2 640×480 @60Hz 31.469 59.940
3 640×480 @67Hz 35.000 66.667
4 640×480 @75Hz 37.500 75.000
5 800×600 @56Hz 35.156 56.250
6 800×600 @60Hz 37.879 60.317
7 800×600 @72Hz 48.077 72.188
8 800×600 @75Hz 46.875 75.000
9 832×624 @75Hz 49.725 75.000
10 848×480 @60Hz 37.879 60.132
11 1024×768 @60Hz 48.363 60.004
12 1024×768 @70Hz 56.476 70.069
13 1024×768 @75Hz 60.023 75.029
14 1280×720 @60Hz 45.000 60.000
15 1280×960 @60Hz 60.000 60.000
16 1280×768 @60Hz 47.776 59.870
17 1280×768 @75Hz 60.776 75.070
18 1280×1024 @60Hz 63.981 60.020
19 1280×1024 @75Hz 79.976 75.025
20 1360×768 @60Hz 63.981 60.020
21 1440×900 @60Hz 64.981 60.050
22 1440×900 @75Hz 66.981 75.070
