Assembly step 3

Cylinder

Chamber Wall

Cylinder Chamber

Wall

Cylinder

Chamber

Supports

M6Nut

(A)

Fit the cylinder chamber wall to the cylinder chamber supports

using 6 dome head bolts (Ref. B) and 6 M6 nuts (Ref. A)

Page 5

M6x10 Dome

Head Bolt (B)
