Assembly step 2

Lower

Support Pole

M6x12

Dome Hex Bolt (C)

M6 Nut (A)

M6x12 Bolt

Cylinder chamber

supports

Fix lower support pole to cylinder chamber supports as shown

using 6 M6 bolts (Ref. C) and 6 M6 nuts (Ref. A)

P

age 4
