Assembly step 1

Base x 1

Cylinder chamber

supports

Base

Upper & Lower

Cylinder Chamber

Supports (A,B,C)

Fix the cylinder chamber supports. (A,B,C) to corresponding location on the

base with 6 M6 bolts (Ref. C).

Page 3

M6 Bolt (C)
