User's Manual

Contents
Safety Reminder . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .
Parts List . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . .
Connector Diagram . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . ..
Op erationse .. . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . .
Key Functions . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .
1
2
3
4
5
Contents
PAGE 1
We strongly recommend a professional technician to setup hands-free car
kit into car audio system. The technician is well equipped for the knowledge
and abilities of car kit installation. Improper installation may cause
unexpected damages. The following items are regarded before the unit
installed.
● Confirm vehicle voltage supply is 12V output
● Toleration ranges from 9V to 16V
● Check mute function to be available for car audio system
● Additional speakers are needed when there is no audio output in the car
● Suitable locations for microphone
1.At least 80 cm distances from microphone to speaker
2.On the car's A-pillar
3.On the dashboard
4.On the steering column
● Unsuitable locations for microphone
1.Close to the car speaker less than 80 cm
2.Under the dashboard
3.Set to the ventilator of car air-conditioner
● Suitable locations for the control unit
1.Specific built-in center console
2.Behind the panel of the center console
3.Behind the lower dashboard
● Unsuitable locations for the control unit
1.Within the airbag area of action
2.In the engine compartment
