IQ3 Data Logger Dash Installation Manual
25
Setting as
Displayed on
Dash
Program
Setting Description
Programming
Command
Accept and
Advance
Accept and
Exit
GEAR RATIO X
X=Gear Number
Ratio between engine
RPM and GPS speed
(not final drive ratio)
Requires tach signal
Recommend
programming in Setup
Mode 2
Short Press
Button 2
Advances by .1
Medium Press
Button 2
Decreases by 5
Long Press
Button 2
Quickly advances
Short Press
Button 1
Long Press
Button 1
TIME ZONE GMT
Sets data and time
stamp on run file,
based on customer
location time zone in
relation to GMT.
East coast standard
time USA = -5 GMT
Short Press
Button 2
Increases by 1
Medium Press
Button 2
Decreases by 1
Short Press
Button 1
Long Press
Button 1
SPEED UNITS
Defines Speed in MPH
or KMH for dash display
purposes
Short Press
Button 2
Toggles MPH and
KPH
Short Press
Button 1
Long Press
Button 1
S/F DETECT
10/20/40/80/160/320
Distance in meters, in
which the start/finish
point is projected
perpendicular to
vehicle. Typical utilized
by boat racers.
Short Press
Button 2
Advances
Short Press
Button 1
Long Press
Button 1
DEFAULT DISPLAY
Default page on power
up. If all positions are
disabled, that page will
not be displayed.
1 = Min
4 = Max
Short Press
Button 2
Advances
Short Press
Button 1
Long Press
Button 1
ODOMETER Odometer value
Short Press
Button 2
Advances by 10
Medium Press
Button 2
Decreases by
1000
Long Press
Button 2
Short Press
Button 1
Save and exit
Setup Mode 1
Long Press
Button 2
Save and exit
Setup Mode 1
