Manual

6
• Engine Speed Pickup
Compatible with most trigger systems:
- 5 or 12-volt square wave;
- Pull-to-ground (open collector)
A Reluctor adaptor is available for magnetic (or ‘reluctor’) triggers supporting most standard tooth
patterns. Applications requiring a motronic trigger input need to be specified at the time of order.
Only a 60-tooth wheel with 2 teeth missing is supported.
ECU Outputs
• Ignition Output
Optional ECU triggered Haltech Ignition Module for firing the coil.
(May also be compatible with other igniters. Ask your Haltech dealer.)
System Programming Requirements
• Computer
IBM-PC or compatible, preferably laptop or notebooks
CGA, EGA or VGA, colour or monochrome display
640+ kb RAM
• Disk Drive
3.5" Floppy Disk Drive
(5.25" disk available on request)
• Serial Port
Standard RS232C port - 9 pin D connector
(25 pin cable available on request)
COM1 or COM2 (selectable)
Adjustable Features
• Ignition Map
22 Ignition ranges, every 500 RPM to 10,500, or
17 Ignition ranges, every 1000 rpm to 16,000
32 Load points per range, up to 50° advance, with 1° resolution
