Use and Care Manual

Introduction of Your Refrigerator's Functions Introduction of Your Refrigerator's Functions
Control buttons
1
Refrigerator temperature control
Freezer temperature control
2
Energy saving mode
3
Auto mode
4
Ice-making switch
5
Child Lock
6
Display items
7
Fast-cooling icon
Fast-freezing icon
8
Energy-saving icon
9
Freezer compartment icon
14
Refrigerator indicate
15
Freezer indicate
16
Auto icon
10
Ice-making icon
11
Locked icon
12
Refrigerator compartment icon
13
Off icon: means refrigerator
shut down
17
Refrigerator temperature
18
Freezer temperature
19
Initial power-on status
All on
Locking and unlocking
When the“LOCK”icon on the display screen is not illuminated, the door
is not locked. In order to activate the child-proof lock, press the CHILD LOCK
button.The“LOCK”icon will illuminate and the door will be locked.To unlock,
press and hold the CHILD LOCK button forthree seconds. The “LOCK” icon
will go out and the door will be unlocked. If no other keys are pressed within
25 seconds of the door being unlocked, it will automatically re-lock.
The below functions can be performed while in the “Unlocked”status.
Energy saving mode
In order to save energy, this mode sets the temperature in the refrigerator at
45℉ and the temperature in the freezer at 5℉, “AUTO” mode default
settings are 41℉ and -0.4℉, respectively .
To activate the “Energy Saving”mode, Press the ENERGYSAVING MODE
buttonand the“ENERGY SAVING”icon will illuminate. Enabling the
energy saving mode for the refrigerator will automatically disable all other
modes.
To de-activate “Energy Saving” mode, do any of the following:
1. Select another mode.
2. Press REF. TEMP. or FRZ. TEMP. to exit setup.
3. ENERGYSAVING MODE button to exit the energy-saving mode
when any of the above situations occur.
Press
4. AUTO MODE to exit the energy-saving mode when any of above
situations occurs.
Press
Auto mode
This function will set the temperature of the refrigerator to 41℉and the freezer
compartment to -0.4℉ .If the refrigerator compartment is turned off, the auto
mode will still be in effect for the freezer compartment.
To activate Auto Mode: Press AUTO MODE and the “AUTO ”icon will
illuminate, indicating the activation of “AUTO MODE”. Selecting “AUTO
MODE”will automatically de-activate all other modes.
1
3
5
7 9 13 15 17
8
1018
11 1214 16 19
2
4
6
21 22
To toggle between Celsius and Fahrenheit display, press and hold the
“AUTO MODE”button for 3 seconds. .
To de-activate AUTO MODE:
1. Select another mode
2. Press REF. TEMP. or FRZ. TEMP. to exit setup.
Fast-cooling mode
This mode is used to counteract a sudden rise in the temperature of the
refrigerator compartment,such as when a large amount of items is placed into
the refrigerator after a trip to the supermarket.The compressor will work for
longer cycles to maintain the desired temperature.
To activate the mode: Press REF Temp for three seconds and the“Super
Cool ”icon will illuminate. When the fast-cooling mode is activated for the
refrigerator compartment, all other modes are automatically de-activated.
The“Fast-Cooling”mode can be de-activated by doing any of the following:
1. Activate the “Energy-Saving” or “AUTO” mode;
2. Press REF. TEMP. to adjust the temperature;
3. Hold down REF. TEMP. for three seconds.When the temperature of the
refrigerator compartment reaches the set temperature,“Fast-cooling”mode
will be automatically de-activated.
