Pump Rating Chart for
American Models PSD/PSDB/CSD/CSDB/FSD 125
1250 GPM at 150 PSI
Single Stage Pump -10-inch Impeller
Use this chart to select the proper engine to pump ratio. The approximate pump input speed and horsepower requirements shown are for the
underwriter rating*.
Maximum lift at which the pump will do the rating at sea level: ****
With 20 feet of 6-inch suction hose is 16 feet
Maximum elevation at which the pump will do the rating on 10-foot lift: ****
With 20 feet of 6-inch suction hose is 4900 feet.
10-FOOT LIFT, 20 FEET OF 6-INCH SUCTION HOSE WITH SUCTION TUBE AND HOSE STRAINERS
INPUT DRIVE SHAFT SPEED -- RPM Rated Capacity Capacity
US GPM
Pressure
PSIG*
Horsepower
Required
Ratio: 2:37 Ratio: 2.16 Ratio: 1.81 Ratio: 1.59 Ratio: 1.40
1675 1840 2195 2500 2840Rating* 1250 150 158
Torque >
496 445 373 326 285
1710 1880 2240 2550 2895Rating” 1250 165 170
Torque>
522 473 393 343 301
1750 1920 2290 2610 2960Rating* 875 200 151
Torque>
453 413 346 304 268
1905 2090 2495 2840 3225Rating* 625 250 162
Torque>
447 407 341 300 264
High Pressure*** 200 300 160 1925 2110 2520 2865 3255
* Engine speed must not exceed manufacturer's maximum no-load governed speed.
** Gauge pressure does not include lift or suction losses.
*** The pump is capable of the high pressure performance shown; actual obtainable pressure should be checked in advance, and is governed by maximum
engine speed, available horsepower and pump ratio.
**** Maximum lift/elevation listed with direct suction hose pump hookup.
Gross engine power curves represent power without accessories. To obtain net power for pumping, deduct for accessory power losses, and deduct for
elevations above sea level per engine manufacturer's recommendations.
When pump is driven via the front engine crankshaft PTO or transmission PTO, the PTO rating should equal or exceed
pump power requirements.
