LED LCD TV OWNER' S MANUAL MODEL: L E 3 2 B 5 0 Please READ this manual carefully before operating your TV, and retain it for future reference
Contents 1、 Safety and warnings..........................................................................................................2-3 2、 Introduction.....................................................................................................................4 3、 Installation...................................................................................................................... 5-8 4、 Remote Controller..............................................................................
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTION 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions. 8) Do not install near any heat sources such as radiations, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
SAFETY AND WARNINGS High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it falls. To prevent fire or electrical shock hazard, do not expose the television receiver to rain or moisture.
INTRODUCTION Accessories Main features ① Used as Television, display terminal, PC display； Infrared Remote Controller............ 1 ② High luminance, wide viewing angle； Battery(AAA)...............................2 ③ Can store 200 TV programs； User’ s M anual...............................
INSTALLATION KEYBOARD Front panel 1 SOURCE 3 30 MUTE AUDIO ASPECT MENU INPUT OK CH.LIST 1: Remote control sensor. Indicator LED: BLUE RED 3: CH+ CH- EXIT VOL+ CH- CH+ PLAY/PAUSE STOP PREV NEXT POWER ON. STANDBY. Key board REAR AV Connections VIDEO AV INPUT L R VIDEO AV OUTPUT L R AC-INPUT 100-240V~50/60Hz All the terminals are(from left to right): AC POWER SOCKET, AV INPUT, AV OUTPUT. Note: VIDEO and YPbPr share one audio channel.
INSTALLATION ANTENNA Note: Aerial connections: IEC(female). Input impendance: 75 unbalanced. PC STEPS: Be sure both the TV and computer are set to Power off. 1.Connect VGA and audio cable. 2.Connect the power cord. 3.Power on the TV, switch to PC mode. 4.Power on the PC. This sequence is very important.
INSTALLATION VIDEO AV INPUT L R VIDEO AV OUTPUT L R AC-INPUT 100-240V~50/60Hz PRESET MODE (PC) RESOLUTION V.Freq.(Hz) 1 800*600 60 H.Freq.(KHz) 37.88 2 1024*768 60 48.36 3 1360*768 60 47.7 H.Freq.(KHz) NOTE: PC V.Freq.(Hz) not more than 60Hz. PRESET MODE (HDMI) RESOLUTION V.Freq.(Hz) 1 800*600 60 37.88 2 1024*768 60 48.36 3 1360*768 60 47.7 4 1280*768 60 47.3 5 1920*1080 60 67.
INSTALLATION AV EQUIPMENT This TV provides one group of AV ,one group of YPbPr for convenient connection to VCR, DVD or other video equipment. Please refer to the owner's manual of the equipment to be connected as well. You can use the input terminals on TV set rear as follows.
REMOTE CONTROLLER The remote control cannot be operated unless the batteries are properly loaded inserted. When using the remote control, aim it at the remote control sensor on the TV. Function introduction 1 USB MUTE 3 2 PICTURE AUDIO ASPECT SLEEP 4 5 13 14 6 1.Press to turn on and off the TV. 2.USB:Press to launch the USB multimedia mode 3.Switches the TV sound on or off. 4.Press repeatedly to cycle through the available picture modes. 5.
TV OPERATION 1. CHANNEL MENU The first item of the MENU is channel menu ( for TV source only). You can search channels and edit programs here. Press to move, press OK button to confirm, and press to adjust. Delete Press to choose the program. Press red button, the program will delete. Rename Rename Move the cursor to the program, press green button to rename the program. Press to choose the character. Press to move the cursor. Press MENU button to exit edit, Press EXIT to exit the menu.
TV OPERATION 3. SOUND MENU The third item of the MENU is the SOUND MENU. You can adjust the sound effect here such as treble, bass, balance etc. Press to move, press OK button to confirm, and press to adjust. OSD Language English Restore Factory Default Blue Screen OSD Blend < Sound Mode Standard Balance Auto Volume Surround Sound < NOTE: Restore factory default will clear all the programs and Reset all the settings to default value. > SOUND > OPTION 6.
TV OPERATION Press to select the function icon, press OK button to confirm the function. Press or EXIT button to exit the control bar. NOTE: You can adjust the audio track, subtitle, or program in the Info menu while Playing the video file. Choose the Info icon and press OK can display the Info MENU. 1/1 Return C Sample1.ts Resolution: 720x576 Press the to select the right disk and press OK to display media files and folder list or choose Return to back to the media type selection menu.
TV OPERATION Hotel Mode: Please press source key first,and then press number key “1001” to enter into Hotel Mode. Hotel Mode Operation Hotel Mode Operation Panel key lock Max volume Start Source Start Channel Setup Menu display Input source change Save To USB Load Volume default OFF OFF 100 TV 1 Yes Yes 0 Hotel Mode Operation: Set Hotel mode on/off. Panel key lock : Keypad will be locked, when Key Lock mode is on. Max volume: Set max volume limitted.This option allows you to set the Max Volume Level.
TROUBLE SHOOTING Trouble phenomenon Picture Audio Snow Ghost Noise Normal audio Interfere Normal Picture No picture Inspection antenna position, direction or connection antenna position, direction or connection Noise electronic equipment,car/ motorcycle,fluorescent light Mute Volume(inspect wether the mute function on the remote control are started , or audio system are correct or not) Mute Power cord is not inserted Power switch is not opened Contrast and brightness/volume setup Press stan
