Specification Sheet

ManualsBrandsHager ManualsDeadboltOne Sided Grade 2 Deadbolt from the 3200 Collection

3200 Series

Description: Deadbolts > 3200 Series - Grade 2

Applications - Auxiliary and primary locking Door Thickness - 1-3/8'' (35 mm) - 1-3/4'' (45 mm)

- Cylinder Hole: 2-1/8'' (54 mm) Diameter (Cross

Bore)

- 1-3/4" (35 mm) Only - 3214 w/ Interchangeable

Core

- Latch Hole: 1'' (25.4 mm) Diameter (Edge Bore)

Backset - 2-3/4'' (70 mm)

Certifications - BHMA Certified ANSI A156.5 Grade 2 - 2-3/8'' (60 mm) - Optional

- ANSI A250.13 Severe Windstorm Resistant

Component

- UL/cUL Listed for all functions up to 3 hours Latchbolt - 1'' (25.4 mm) Throw-Brass with concealed

hardened steel roller to prevent sawing or

cutting

- UL10C/UBC 7-2 (1997) Positive Pressure Rated - 2-1/4'' (57 mm) x 1-1/8'' (29 mm) Square Corner

Faceplate

- UL10B Neutral Pressure Rated

- ADA - Thumbturn Strikes - 3930 Square Corner, 1-1/8'' (29 mm) x 2-3/4''

(70 mm) with dustbox - Standard

- 3929 ASA Deadbolt Strike - Optional

Exposed Trim - Wrought Brass, Stainless Steel or Bronze

Functions - 14 Double Cylinder

Mechanism - Steel, zinc plated and dichromated - 15 Single Cylinder

- 20 Thumbturn with blank plate

Keys - Two brass keys per lock - 21 Thumbturn Only (Will replace 3219)

- 22 Retrofit Kit (For use with 3219 and 3221)

Cylinders - Brass 6-pin - Keyed Different - C Keyway

- Other keying options available from the factory

- Interchangeable Core - Brass 6 or 7 pin -

uncombinated and combinated - sold separately

Summary of content (10 pages)

PAGE 1
3200 Series Description: Deadbolts > 3200 Series - Grade 2 Applications - Auxiliary and primary locking - Cylinder Hole: 2-1/8'' (54 mm) Diameter (Cross Bore) - Latch Hole: 1'' (25.4 mm) Diameter (Edge Bore) Certifications - BHMA Certified ANSI A156.5 Grade 2 - ANSI A250.
PAGE 2
Hager Companies, Inc 139 Victor Street Saint Louis, MO 63104 HAGER TEST REPORT NO.: LS04003 EVALUATION OF Hager Companies 3200 Series Grade 2 Single Cylinder Deadbolt TEST PARAMETERS: This report covers tests and/or evaluations performed using the following standard(s) as a guideline: ANSI/BHMA A156.5-2001 American National Standard for Auxiliary Locks and Associated Products. Testing was conducted by Intertek Testing Services NA, Inc., at their Middleton, WI facility.
PAGE 3
ITEM QTY. FILE NAME NO. 1 1 S-LS00007 DESCRIPTION 3940 DEADBOLT LATCH (2-3/4" BACKSET) 2 1 S-LS00728 CYLINDER ROSE 3 1 S-LS00726 CYLINDER ROSE LINER 4 1 S-LS00718 EXTERIOR DOUBLE CYLINDER HOUSING 5 1 S-LS00717 INSIDE THUMBTURN ASSEMBLY 6 1 S-LS00723 DEADBOLT STRIKE 7 1 S-LS00724 DEADBOLT WOOD REINFORCER 8 1 S-LS00725 DEADBOLT DUST BOX 9 1 S-LS00379 STANDARD CYLINDER FIRE SHIELD 10 2 S-LS00883 CUSTOM #12-24 X 2-5/8" FPHMS 11 1 S-LS00617 6-PIN DRILLED CYLINDER 11.
PAGE 4
ITEM FILE NAME NO. 1 S-LS00007 2 S-LS00728 DESCRIPTION QTY.
PAGE 5
ITEM FILE NAME NO. 1 S-LS00007 DESCRIPTION QTY. 3940 DEADBOLT LATCH (2-3/4" BACKSET) 1 2 S-LS00728 CYLINDER ROSE 2 3 S-LS00726 CYLINDER ROSE LINER 2 4 S-LS00718 EXTERIOR DOUBLE CYLINDER HOUSING - IC 1 4.6 S-LS00606 TAILPIECE (2-639-7091) 1 5 S-LS00718 INTERIOR DOUBLE CYLINDER HOUSING - IC 1 5.
PAGE 6
ITEM FILE NAME NO. 1 S-LS00007 DESCRIPTION QTY. 3940 DEADBOLT LATCH (2-3/4" BACKSET) 1 2 S-LS00728 CYLINDER ROSE 1 3 S-LS00726 CYLINDER ROSE LINER 1 4 S-LS00718 EXTERIOR THUMBTURN CYLINDER HOUSING - IC 1 4.
PAGE 7
ITEM NO. FILE NAME Description QTY.
PAGE 8
ITEM NO. FILE NAME Description QTY.
PAGE 9
LOCKS 3200 SERIES LOCKS HOW TO ORDER 3 3214 2 /8” US3 US26 SCC Interior Finish (if different) Function 14 - Double Cylinder 15 - Single Cylinder 20 - Thumbturn with Back Plate 21 - Thumbturn 22 - Retrofit kit for 3220/3221 Finish US3 US4 US10 US10B US26D US32 US32D Product Group Backset/Faceplate 2-3/4” 2-3/4” 2-3/8” 2-3/8” Notes: 1.
PAGE 10
The following products have been approved for statewide acceptance by the Florida Building Commission pursuant to Rule 9B72.090, F.A.C., for approval of products and systems for use on Exterior Swinging Door Assemblies, in compliance with the structural requirements of the 2007 Florida Building Code. Verification of Florida Statewide acceptance can be found at www.floridabuilding.org under the Product Approval section. Severe Windstorm Resistant Components for Swinging Door Assemblies ANSI A250.
