Specification Sheet
Call 1-800-423-3531 from anywhere in the US - www.hafele.com™
167 A
Dimensional data not binding. We reserve the right to alter specifications without notice.
Sliding Wood
+PTLUZPVUZPUTTHYLL_HJ[
0UJOLZHYLHWWYV_PTH[L
Top Hung System
Straightaway 50
• Internal straight sliding door hardware, soffit mounted
for residential and light duty commercial use
• Maximum door weight: 50 kg (110 lbs.)
Maximum door height: 2.1 m (6’ 10 11/16”)
Door thickness: min. 25 mm (1”)
15 ±3 mm
9
16"
1
8"
39
9
16"
24
15
16"
1
13
1
2"
27
24
1
16"
1
15
16"
Straightaway 50 Single Top Track, un-drilled
Material: aluminum, anodized
Length Item No.
2.5 m (8’ 2 7/16”)
940.55.925
Packing: 1 pc.
Straightaway 50 fitting set
1 Set
consisting of:
Description Material/Color/Finish
940.55.000
Qty.
Running gear, with four nylon
wheels and integral ball bearings
Aluminum;
Mounting plate: Zinc alloy
2 pcs.
Track stopper, for mounting in top track Plastic, white 2 pcs.
Bottom guide, for screw-mounting to floor Steel, galvanized 1 pc.
Packing: 1 set (includes mounting materials)
15
9
16"
40
9
16"
1
16
5
8"
20
13
16"
30
3
16"
1
31
1
4"
1
35
3
8"
1
22
7
8"
18
11
16"
20
13
16"
80
1
8"
3
New
Item
