Assembly Instructions

2
Components - Parts
Please check you have all the parts listed below
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
Seat
(2 x 39.5 x 40cm)
3Front Leg
(4.5 x 37 x 42cm)
2
Side Rail x 2
(2 x 6 x 33cm)
4 Stretcher x 2
(1.2 x 2.2 x 36cm)
5Backrest
(8 x 40 x 89cm)
1
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly of 1 chair. In some cases more
fittings may be supplied than are required.
A
Wooden dowel x 6
B
Spring washer x 6
C
M6 x 50mm Bolt x 6
D
M4 x 32mm Screw x 7
E
Allen key x 1
Tools required
Crosshead screwdriver
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Note: The quantities below are the correct amount to complete the assembly of 1 chair.
