Instruction Manual name: AllPro model number: HS-20 “Clean and sanitize nearly everything in & around your home.” CK LO LO UN HAAN ® Corporation 1866 Colonial Village Lane Lancaster, PA 17601 phone: 877-422-6347 www.HAANusa.
Copyright ©2011 HAAN® Corporation Notice The information contained in this document is subject to change without notice. HAAN® Corporation assumes no responsibility for any errors that may appear in this document nor does it make expressed or implied warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Introduction Congratulations on purchasing a HAAN® product. Now you have an easy way to clean just about anything in and around your home. Your handheld steam cleaner uses steam to remove tough grease, dirt and grime. Steam is nature’s purest and most powerful cleaner for safely cleaning all hard surfaces in your home without harsh chemicals, for a perfectly ecological approach. No film, no residue – just clean, germfree floors.
Important Safety Instructions Basic precautions should be observed when using an electrical appliance, including the following: IMPORTANT 1. Be sure to read ALL instructions and warnings before using your HAAN® Steam Cleaning Sanitizer. 2. 3. 4. Warning 5. 6. Risk of electrical shock: Be sure to read and follow all instructions and warnings. CAUTION 7. 8. 9. The HS-20 emits steam at 212˚F to sanitize the area of use.
Important Safety Instructions 19. 20. 21. 22. 23. 24. IMPORTANT Warning DO NOT modify the plug. Improper connection of the equipment-grounding conductor can result in a risk of electrical shock. If an extension cord is necessary, a minimum of 15 ampere/14 gauge cord should be used. Cords rated for less may overheat. Never put descaling, aromatic, alcoholic or detergent products into the steam cleaner, as this may damage it or make it unsafe for use. Unplug by grasping the plug, not the cord.
Operating Instructions Care & Maintenance IMPORTANT Always ensure that your handheld steamer is UNPLUGGED from the wall receptacle prior to cleaning or emptying the water tank. 1. 2. 3. 4. CAUTION Do not immerse your handheld steamer in water or any other liquid. 5. 6. 7. 8. 4 Unplug the handheld steamer from the electrical outlet after every use. When storing, organize the power cord by using the supplied twist tie.
Product Parts 2 1 3 LO CK 4 UN LO CK 5 8 6 DY STEAM REA 9 10 11 12 1. Steam Nozzle 2. Pressure Locking Safety Cap 3. Easy Control Trigger 4. Continuous Steam Lock 5. Main Body / Water Tank 6. Indicator Lights 7. Power Cord 8. Concentrator Nozzle 9. Wire Bristle Brush 10. Detail Brush 11. Angled Nozzle 12. Accessory Bag 13. Flexible Extension Hose 14. Measuring Cup 15. Garment/Surface Attachment 16.
Before Using Your Handheld Cleaner Be sure to read ALL instructions and warnings before using your Handheld Cleaner. CAUTION After plugging in the power cord and beginning to heat, a fixed amount of water is released due to the build-up of internal pressure. After heating is complete, spray the steam 2 to 3 times before affixing or switching any additional attachment. CAUTION Use a grounded receptacle. Use only a heavy duty extension cord rated for 15 amps minimum – DO NOT use an ordinary extension cord.
4 5 6 OPEN OPEN CLOSE OPEN CLOSE CLOSE CLOSE OPEN LOC K UN LOC K Turn the Pressure Locking Safety Cap clockwise to tighten. The cap will spin freely when properly tightened. To attach the Concentrator Nozzle, Flexible Extension Hose or Garment/Surface Attachment, line up the indicator line on the accessory attachment with the indicator line on the handheld unit. 7 8 LO C K Press accessory attachment onto the Steam Nozzle and rotate to the “Closed” position.
K UN LO CK Refilling The Water Tank During Use 1 2 DY STEAM REA 3 POWER LO CK UN LO CK Steam will stop being emitted from the nozzle when the Water Tank is empty. The Steam Ready Light will also go off when the tank is empty. Unplug the unit from the electrical outlet. 4 Press the Easy Control Trigger to release all steam remaining inside the tank. 5 NOTE: When finished steam cleaning always empty any left over water from the water tank.
Using The Accessories Continued Flexible Extension Hose: Adds maneuverability when cleaning hard to reach areas. Wire Bristle Brush Attachment: Can be used with the Concentrator Nozzle and Flexible Extension Hose. Perfect for scrubbing and steam cleaning hardened and oily grime from kitchen countertops, stovetops, cutting boards, outdoor grilles, etc. Detail Brush Attachment: Can be used with the Concentrator Nozzle and Flexible Extension Hose.
Troubleshooting Problem Water leaks from nozzle. Solution • Use no more than 200ml of water in the tank per use. • Ensure unit is in an upright position. • Wait until the start-up heating cycle is complete. Unit not operating. • Ensure plug is set firmly in outlet. • Replace fuse or reset breaker. Unit does not emit steam. • Ensure water tank is filled with water. Accessory is loose. • Reattach accessory and ensure it is tight and properly attached. Steam emitted when refilling the water tank.
Commonly Asked Questions Q: What surfaces can be sanitized by using the steam cleaner? A: Your steam cleaner is designed to clean hard surfaces like laminates & countertops, stovetops and tile, ceramic and glass as well as upholstery; any surface that will withstand high heat. DO NOT use on soft plastic and cold glass. On surfaces that have been treated with wax, or on some no-wax floors, the sheen may be removed by the heat and steam. DO NOT use on unsealed wood. This could cause the wood panel to rise.
Product Specifications: Model HS-20 Color Mango Size 5.2” W x 8.8” D x 8.5” H Weight 2.8 lb Voltage/Hz 12V, 60Hz Wattage 1000 watts Cord Length 14’ 9” Tank Capacity 6.76 fluid ounces (200ml) Heat-up Time less than 3 minutes Operating Time 15 minutes before refill is needed *Base Dimensions approximated. Base depth measured without nozzle or attachments.
Product Registration Please fill out and mail this Product Registration Card within thirty (30) days of purchase in order to validate the fore said Limited Warranty. The registration will allow us to contact you in the unlikely event of a product safety notification. By returning this card you acknowledge that you have read and understood the instructions for Country/Territory State/Province Last Name use and the warnings set forth within the instructions.
Place Stamp Here Product Registration HAAN® Corporation 1866 Colonial Village Lane Lancaster, PA 17601 3) Where did you purchase your HAAN® product? 4) How did you hear about HAAN®? 5) We like to hear from our product owners.
