H·KING NOTICE Thank you for purchasing from AF- Model. Please read this manual carefully before operating this plane. We hope this manual is useful in guiding you through the installation and adiustment of the plane so that you may fly it successfully. Each product from AF-Model has unique functions that users will need to fully grasp step by step, as the assembly will be completed by you. It is necessary to assemble and test the product strictly in accordance with the standards of AF- Model.
H·KING H·KING TROUBLE SHOOTING CONTENTS Box Contents....................................................................................01 Problem Cause Motor does not turn 1. Battery is not fully charged 2. Transmitter battery low 3. Motors not connected 4. The motor is damaged 5. Reciever is not bound to Tx 6. ESC in set-up mode Model moves backwards 1. Both ESC and motor are not establishing a proper response range S p e c i f i c a t i o n s ....................................................
Attention Main gear retract unit Front gear leg only Left main gear leg Right main gear leg EDF jets require Li-PO batteries with a high discharge rating (C rating) for increased safety and optimal performance.We recommend using lI-Po batteries with a minimum of 40C or above.
Fixed with screws PA2.6*10MM 2pcs Fuselage(orange) Nose Cone(orange) Left Wing(orange) Right Wing(orange) Plug the nose part to the fuselage. Tail and elevator(orange) Fixed with screws PM3*8MM 4pcs Assembly of your Sport Jet is completed. Now perform a final check on all screws, bolts and components, ensuring all are secure and firmly in place.
Control Horn and Servo Arm Setting CG LOCATION Horns Arms Elevator +10mm -10mm The Rudder Rudder The Rudder The front wheel steering The front wheel steering +10mm -10mm CG:140mm Ailerons +10mm -10mm 06 More control throw Less control throw 03
